Philips 160E1SB/93 - Electrical Block Diagram; Main Board


17
Meridian 1
5.2 Electrical Block Diagram
5.2.1 Main Board
Flash Memory
PM25LV010A
(U402)
Panel Interface
(CN405)
Crystal 12MHz
(X401)
Keypad Interface
(CN401)
Scalar IC NT68167FG
(Include MCU, ADC, OSD)
(U401)
D-Sub Connector
(CN101)
ESD AZC099-04S
(U103)
H sync
V sync
RGB
ESD AZC099-04S
(U102)
VGA_R+
VGA_G+
VGA_B+
H_Sync
V_Sync
DSUB_SCL
DSUB_SDA
EEPROM
M24C16
(U407)
