Meridian 1
Software control functions via OSD/Control adjustment functions
Please refer to following Hudson 9 OSD definitions, if any deviation, there refer to PVT exit sample.
ITEM
1 OSD DEFINITIONS
ˣ˛˜˟˜ˣ˦ʳ˄ˉ˃˘˄ʳˢ˦˗ʳ
˗˸˹˼˼˼ˀ˃ˋ˄˃˅˅˅ˁ
Reset -
No: Exit
Yes: Auto adjustment for displaying
timing mode and recall factory preset
2 OSD LANGUAGES
˛ˋʳˢ˦˗ʳ˴˿˴˼ʳˀʳ
˅˃˃ˊ˃ˇ˅ˈʳˀʳ˙˼˴˿ˁ˿
˛ˌʳ˸ʳ˼˸ʳ
˴˿˴˼ʳ˲ʳ˅˃˃ˋ˃ˇ˄
9 LANGUAGES
3 OSD TREE
ˣ˛˜˟˜ˣ˦ʳˢ˦˗ʳ
˧˸˸ˀ˃ˋ˄˃˅˅ˁ˿
4 POWER ON LOGO
˄ˆˉˉˊˉˋˁ˵
Power On Logo: Power On Æ Show
up Philips logo 3 seconds Æ Change to
input signal.
This picture is reference only. The
official drawing will send out by PM.
Timing requirement
Factory Preset mode definition:
1. Perfect FOS while presenting those timings
2. Will specify those timing in User’s Manual
Preset mode definition:
1. Need to support those timings
2. Perfect FOS after auto adjustment
User mode
1. Can save those timing that not in preset mode and can be showed (not over scalar or panel spec.)
2. It needs to reserve the 10 timings space in memory size.
Mode storing capacity
Factory preset modes : 08
User modes :23
Factory preset modes (8 modes)
x Factory modes and preset modes are defined in the enclosed timing table file
˄ˉ˃˘˄ʳ˄ˆˉˉʳˊˉˋʳ
˧˼˼˺ʳ˧˴˵˿˸ˀ˃ˋ˄˃
x Video timing mode (internal firmware support)
60Hz: 480p/720p/1080i/1080p
50Hz: 576p/720p/1080i/1080p
