61
General Product Specification
8639 000 16452
2005-04-25
590
11
26
Peter.V
17 inch TFT-LCD Monitor
TYPE : 170C6FS/00
BRAND : PHILIPS
2005-04-25
MODE NO. 13 14 15 16
RESOLUTION 832 x 624 1024 x 768 1024 x 768 1024 x 768
Dot clock(MHz) 57.28 65 75 78.75
f h49.7kHz 48.363kHz 56.5kHz 60kHz
A (us) 20.11(1152 dots) 20.677(1344 dots) 17.707(1328dots) 16.66 (1312dots)
B (us) 1.117(64 dots) 2.092(136 dots) 1.813(136 dots) 1.219 ( 96 dots)
C (us) 3.91(224 dots) 2.462(160 dots) 1.920(144 dots) 2.235 ( 176 dots)
D (us) 14.52(832 dots) 15.754(1024 dots) 13.653(1024 dots) 13.003(1024 dots)
E (us) 0.563(32 dots) 0.369(24 dots) 0.321 (24 dots) 0.203( 16 dots)
fv 75Hz 60.004Hz 70.004Hz 75Hz( 75.000)
O(ms) 13.41(667 lines) 16.666(806 lines) 14.272(806 lines) 13.328(800 lines)
P (ms) 0.06(3 lines) 0.124(6 lines) 0.106(6 lines) 0.05(3lines)
Q(ms) 0.784(39 lines) 0.600(29 lines) 0.514(29 lines) 0.446 ( 28lines)
R (ms) 12.55(624 lines) 15.880(768lines) 13.599(768lines) 12.80 (768lines)
S (ms) 0.016(1 lines) 0.062(3 lines) 0.053(3 lines) 0.017 ( 1 line)
SYNC. H/V+/+ -/- -/- + / +
POLARITY
SEP . SYNCYY YY
MODE NO. 17 18 19 20
RESOLUTION 1024 x 768 1024 x 768 1152 x864 1152 x864
Dot clock(MHz) 83.096 94.579.994.5
f h61.1kHz 68.7kHz 54.0kHz 63.9kHz
A (us) 16.367 (1360dots) 14.561 (1376 dots) 18.523(1480 dots) 15.661(1480 dots)
B (us) 1.348(112 dots) 1.016 ( 96 dots) 1.952(156 dots) 1.016(96 dots)
C (us) 2.022 ( 168dots) 2.201 ( 208dots) 1.352(108dots) 1.116(105 dots)
D (us) 12.323(1024 dots) 10.836 ( 1024 dots) 14.418(1152 dots) 12.19(1152 dots)
E (us) 0.674 ( 56 dots) 0.508( 48dots) 0.801(64 dots) 1.339(127 dots)
fv 76Hz85Hz 60Hz 70Hz
O(ms) 13.142 (803lines) 11.765 (808lines) 16.671(900lines) 14.283(912lines)
P (ms) 0.049 (3lines) 0.044 (3lines) 0.148(8 lines) 0.047(3lines)
Q(ms) 0.507 (31 lines) 0.524 (36 lines) 0.445(24 lines) 0.689(44 lines)
R (ms) 12.57 (768lines) 11.183 (768lines) 16.004(864 lines) 13.531(864 lines)
S (ms) 0.016 ( 1 line) 0.014 ( 1 line) 0.074(4 lines) 0.016(1 lines)
SYNC. H/V+/ ++/ ++/++/+
POLARITY
SEP . SYNCYY YY
