Philips 170S5FG/00 - GENERAL PRODUCT SPECIFICATION; Brightness uniformity; Check Cross talk (S)

GENERAL PRODUCT SPECIFICATION
56
170S5 LCD
Go to cover page
17 inch LCD Monitor
TYPE : 170S5FG/00
BRAND : PHILIPS
8639 000 15092
2004-01-16
2004-01-16
590
16
24
JERRY CHEN
Apply Pattern 2. Set contrast at 50 % and brightness at 100 %. Measure A.
Then output Pattern 3 and measure A'. The cross talk value:
A X 100 % < 1.5 % (Max)
4.7 White color adjustment
ABS ( A - A' )
10 1024X768 60.0KHz 78.75 75Hz
11 1024X768 48.4KHz65 60Hz
12 1152X870 68.7KHz 100 75HzMAC
13 1152X900 71.8KHz 108 76HzSUN Mode II
14 1280X1024 64.0KHz 108 60Hz
15 1280X1024 80.0KHz 135 75Hz
Note: 1. Screen displays perfect picture at 15 factory preset modes.
2. Screen displays visible picture with OSD warning when
input modes are other then 34 preset modes
4.3 Brightness: 200 nits (at panel color temperature, Screen center point, Fig.
1)
4.4 Image size
4.4.1 Actual display size
338x270mm
4.5 Brightness uniformity
Set contrast at 50% and turn the brightness to get average above 200
nits at center of the screen.
Apply the Fig 1. It should comply with the following formula:
Minimum luminance of nine points (brightness)
>= 0.75 (Min)
Maximum luminance of nine points (brightness)
4.6 Check Cross talk (S)
