3.3 Timing requirement
Factory Preset mode definition:
1. Perfect FOS while presenting all required timings.
2. Required timings need to be specified in User’s Manual.
User mode
1. Can be showed (not over scalar or Panel spec.)
2. It needs to reserve the 22 timings space in memory size.
3.3.1 Mode storing capacity
Factory preset modes : 10
User modes : 23
Note: 1. Screen displays perfect picture at 10 factory-preset modes.
2. Screen displays visible picture with OSD warning when input modes are the 22 preset modes.
3.3.2 Factory preset modes
Factory modes and preset modes are defined in the enclosed timing table file.
Support
Timing
Factory
Preset
Timing
Resolution
Pixel Rate
( MHz )
Horizontal
( KHz )
Vertical
( Hz )
* DOS 640x350/70 25.18 31.47 70.09
* * DOS 720x400/70 28.32 31.47 70.09
* * DMT 4:3 640x480/60 25.18 31.47 59.94
* MAC 640x480/67 30.24 35.00 66.67
* DMT 4:3 640x480/72 31.50 37.86 72.81
* * DMT 4:3 640x480/75 31.50 37.50 75.00
* DMT 4:3 800x600/56 36.00 35.16 56.25
* * DMT 4:3 800x600/60 40.00 37.88 60.32
* DMT 4:3 800x600/72 50.00 48.08 72.19
* * DMT 4:3 800x600/75 49.50 46.88 75.00
* MAC 832x624/75 57.28 47.73 74.55
* WVGA 1024X600/60
* * DMT 4:3 1024x768/60 65.00 48.36 60.00
* DMT 4:3 1024x768/70 75.00 56.48 70.07
* * DMT 4:3 1024x768/75 78.75 60.02 75.03
* DMT 1152x864/75 108.00 67.50 75.00
* MAC 1152x870/75 100.00 68.68 75.06
* SUN 1152x900/66 92.94 61.80 65.95
* SUN 1152x900/76 105.56 71.71 76.05
* CVT 16:9 1280x720/60 74.50 44.77 59.86
* CVT 16:9 1280x720/75 95.75 56.46 74.78
* CVT 15:9 1280x768/60 79.50 47.78 59.87
* CVT 15:9 1280x768/75 102.25 60.29 74.89
* CVT 1280x800/60 83.50 49.70 59.81
* CVT 1280x800/75 106.50 62.80 74.93
* DMT 4:3 1280x960/60 108.00 60.00 60.00
