ʳʳʳʳʳʳʳʳʳʳʳʳʳʳʳʳʳʳʳʳʳ˃ˁ˄ 222E2 21.5” Wide FHD LCD Monitor
2010/02/05 PHILIPS 20 of 30
72 222E2 LCD
General Product Specification
5 Mechanical characteristics
5.1 Cosmetic -
Philips ID
5.2 Mechanical data files -
ProE files required
5.3 Location of Philips logo -
Per Philips make-up sheet
5.4 Gap between panel and front bezel
< 1.2(typ.) mm
5.5 Location of Control icons -
Per Philips Graphic sheet
5.6 Color for resin/paint -
Per Philips make-up sheet
5.7 Fire enclosure request-
Shielding Cover should fulfill international standard
5.8 Resins
x RoHS required
x WEEE required.
x Resin type/selection refer to Project Book Section 7.2 Plastic material.
5.9 If paint is used
x RoHS required
x WEEE require
x If new painting type need to implement, refer to UN-D 1235.
5.10 Plastic mold tooling
x Tooling to be designed to minimize cosmetic defects induced by molding
process (sink, blush, weld lines, gate marks, ejector marks, etc.). Refer to
“TYV61-90007”.
x Painting to cover up cosmetic defects due to molding is strongly discouraged.
x China RoHS mark requested.
