Philips 222E2SB/00 - Firmware Upgrade for CPU

32 222E2 LCD
Firmware Upgrade for CPU
1. Hardware Requirement:
1.1. I2C board x 1 (a.Print Board b. I2C Board)
1.2. DSUB VGA cables x 2
1.3. Printer cable (with one male connector and another female connector) x 1.
1.4. PC or Notebook with parallel (printer) port x1.
1.5 Check the Jumpers on the I2C circuit board (make sure J5/J6/J7/J8 are set at Pin 1 & Pin 2 short)
Print I2C
Connected to print
cord and PC
Connected to Display
Signal Cable
