Philips 226V3LSB/00 - Page 60

60
Meridian 3
U402 070GHDCP500HDC HDCP CODE
X401 093G--2251B--J
CRYSTAL 12MHZ
NXS12.000AC30F-KAB10
IC902 056G-139--9 IC EL817M(X) photocoupler DIP-4
IC801 056G-379185
AC/DC CONVERTER
TA9690GN-A1-0-TR SOP-24
IC901 056G-379190
AC/DC CONVERTER LD7750RGR
SOP-7
IC903 056G-563354 Shunt. Reg. TL431-A-TA TO-92
F1 0FFST-0002A
F0603FA2500V032T, AEM, 2.5, 32 Volt,
1.6X0.8X0.8, SMT, Ceramic, UL/CSA
F901 084G--56-4W FUSE 4.0A 250V
F902 084G--56-4W FUSE 4.0A 250V
E08903 089G-17356C554 AUDIO CABLE 1800MM
E08902 089G-725HAA-2G D-SUB CABLE 1500MM
E08902 089G-725CAA-2G D-SUB CABLE 1500MM 2nd source
E08901 089G404A15N-IS AC POWER CORD 1500MM Europe Reg.
E08901 089G404A15N-CX AC POWER CORD 1500MM Europe Reg. 2nd source
E09503 F95G176J-10113 FFC CABLE 10PIN 168MM 0.5MM
E09503 F95G176X-10113 FFC CABLE 10PIN 168MM 0.5MM 2nd source
E09502 F95G8014-7D100 WIRE HARNESS 500MM 7P-7P
E09502 F95G8014-7X100 WIRE HARNESS 500MM 7P-7P 2nd source
E09502 F95G8014-7R100 WIRE HARNESS 500MM 7P-7P 2nd source
E09501 F95G801830D301 LVDS CABLE 140mm 30P-30P
E09501 F95G801830X301 LVDS CABLE 140mm 30P-30P 2nd source
E09501 F95G801830R301 LVDS CABLE 140mm 30P-30P 2nd source
Recommended Parts List for 226V3LSB/00
ITEM LOCATION PCM CODES DESCRIPTION REMARK
1 FQ101 705GFACS091 BEZEL ASSY
2 FQ004 KEPCAQV6 KEY G4921-K0B-X-X-1-110128
3 FQ001 750GMT215W4A21N100 LM215WF4-TRA2 FQ LTD
4 FQ570 Q52G1801MNT058 MYLAR
5 FQ003 PLPCBB571GQAV POWER G4889-P0D-000-0010-7-110411
6 FQ002 CBPCBN2PHQQ MAIN BOARD
7 FQ124 A15G1654101201 MAIN_FRAME
8 FQ102 705GFACS092 REAR COVER ASSY
9 FQ110 A37G0258011 HINGE_21.5""
