16. Recommended & Spare Parts List
Recommended Parts List for 226V3LAB/00
ITEM LOCATION PCM CODES DESCRIPTION REMARK
1 FQ101 705GFACS085 BEZEL ASSY
2 FQ004 KEPCAQV6 KEY BOARD
3 FQ419 078G020A--6--V SPEAKER
4 FQ001
750GMT215W4A21N10
0
LM215WF4-TRA2 FQ LTD
5 FQ570 Q52G1801MNT058 MYLAR
6 FQ003 PLPCAB571UAAZ POWER BOARD
7 FQ005 AUPCAQV1 AUDIO BOARD
8 FQ002 CBPCAN2PHQJ MAIN BOARD
9 FQ124 A15G1654101101 MAIN_FRAME
10 FQ102 705GFACS086 REAR COVER ASSY
11 FQ110 A37G0258011 HINGE
12 FQ107 A34G2611AFL-1B0100 STAND TOP
13 FQ108 A34G2612AFL-1B0100 STAND BOTTOM
14 FQ118 A33G1215AFL-1B0100 HINGE COVER
15 FQ111 705GFACS087 BASE ASSY
U3 0IDIL-0002A
AP7167-FNG-7, DIODES, ADJUST_3.3V,
1.2A, DFN3030-10, R/TP, 10
U4 0ISGL-0008C
M24C04-RDW, STmicroeletronics, 4K,
5ms, TSSOP, R/TP, 8
U402 056G2233-11 IC Pm25LD020C-SCE SIOC-8(150mil) 2M
U601 056G-616110 AUDIO PAM8007NHR 3W SSOP-24
U602 056G-662-48 ESD PROTECT AZC399-04S SOT23-6L
U401 056G-562369 SCALER NT68660UFG/B TQFP-100
U703 056G-563161
IC AME8815BEGT180Z 1.5A/1.8V
SOT-223
U702 056G-563520 LDO LSP1117D33AG 1A 3.3V TO-252
U102 056G-662-48 ESD PROTECT AZC399-04S SOT23-6L
U103 056G-662-48 ESD PROTECT AZC399-04S SOT23-6L
U104 056G-662-48 ESD PROTECT AZC399-04S SOT23-6L
U106 056G-662-48 ESD PROTECT AZC399-04S SOT23-6L
U107 056G-662-48 ESD PROTECT AZC399-04S SOT23-6L
U101 056G1133956 IC CAT24C02WI-GT3 SO-8
U105 056G1133956 IC CAT24C02WI-GT3 SO-8
U402 056G2233-11 IC Pm25LD020C-SCE SIOC-8(150mil) 2M
