Meridian 3
79
Output Resistance : 1KΩ±20%
(CEC Signal, not supported by this model)
Input Low Voltage : < 0.8V
Input High Voltage : > 2.0V
Output Low Voltage: 0 – 0.4V
Output High Voltage: 2.5V – 3.6V
Pull-up Resistor: 2.7KΩ±10%
Leakage Current in standby/off : < 1.8uA
Maximum Capacitance: 100pF
4). DisplayPort ( option , refer to Quick specification table)
Follow DisplayPort 1.1
specification.
5). USB Hub 2.0 (option , refer to Quick specification table)
USB port (1 upstream, 2 or 4 downstream)
6). Audio in ( option , refer to Quick specification table)
Input signal: 1Vrms
Loudspeaker: stereo of RMS Power
Frequency range: (WAIT FOR SUPPLIER INPUT)
Headphone connection will mute speaker
7). USB PLUG (option , refer to Quick specification table)
USB port (1 upstream, 1 downstream), black jack color
8). HDMI audio out (headphone): (option, refer to Quick specification table)
Stereo, > 50mVrms for headphone of 32
Interface
D-Sub Cable
Length : Please refer to M3 cable bundle summary file
Fix with monitor when packing, with transplant pin protective cover.
Connector type : D-Sub male with DDC2B pin assignments.
Blue connector thumb-operated jack screws
Pin assignments:
PIN No. SIGNAL
1 Red
2 Green/ SOG
3 Blue
4 Sense (GND)
5 Cable Detect (GND)
6 Red GND
7 Green GND
8 Blue GND
9 DDC +3.3V or +5V
10 Logic GND
11 Sense (GND)
12 Bi-directional data
