5. Color Temp confirmation
Connect the signal to the monitor, the monitor displays white-picture, use CA-210 to measure the Color Temp of the
screen center and select the OSD to make sure whether the Color Temps accord with the SPEC.
227E3L
CIE
coordinates
11500K
9300K
8200K 7500K
6500K/sRGB sRGB
5000K
x 0.270±0.02 0.283±0.02 0.291±0.02 0.298±0.02 0.313±0.02 0.313±0.02 0.345±0.02
y 0.281±0.02 0.297±0.02 0.306±0.02 0.314±0.02 0.329±0.02 0.329±0.02 0.357±0.02
247E3L
CIE coordinates 9300K 6500K/sRGB sRGB
x 0.283±0.02 0.313±0.02 0.313±0.02
y 0.297±0.02 0.329±0.02 0.329±0.02
6. How to enter into the factory mode
1. Connect the video source to monitor and AC on.
2. The way to factory menu: Press
and buttons at the same time, power on the monitor. When the
screen lights, release the two buttons and press the “MENU” again, the picture will appear on the top left corner.
