Philips 27PS60S321 - Service Modes, Error Codes, and Fault Finding; Test Points

Service Modes, Error Codes and Fault Finding
Index:
1. Test points.
2. Service Modes.
3. Problems and Solving Tips (related to CSM).
4. Compair.
5. Error Codes.
6. The Blinking LED Procedure.
7. Protections.
8. Repair Tips.
Supporting Overviews
z
I2C-IC overview
z
Test points overview Main Panel
z
Test points overview CRT Panel
Test Points
The chassis is equipped with test points printedon the circuit board assemblies. These test
points refer to thefunctional blocks:
Table: TestpointOverview
Test point Circuit Diagram
A1-A2-A3-.. Audio processing A8, A9 / A11
C1-C2-C3-.. Control A7
F1-F2-F3-.. Frame drive and output A3
I1-I2-I3-.. Tuner & IF A4
L1-L2-L3-. Line drive and output A2
P1-P2-P3-.. Power supply A1
S1-S2-S3-.. Synchronisation A6
V1-V2-V3-.. Video processing A5, B1
Pa
g
e 1 of 16SPMS
7/8/2004
