Philips 27PS60S321 - Page 73

Table: Error Code Table
ERROR Device
Error
description
Check item Diagram
0 Not applicable No Error
1 Not applicable
X-Ray
Protection
2465, 7460 A2
2 Not applicable
Horizontal
Protection
7460,
7461,
7462,
7463, 6467
A2
3 TDA8359/TDA9302
Vertical
Protection
7861,
VloAux
+13v
A2, A3
4 MSP34X5/TDA9853
MAP I2C
identification
error
7831, 7861 A9 or A11
5 TDA95XX
POR 3.3V / 8V
Protection
7200,
7560, 7480
A1, A2.
A5, A6,
A7
6 I2C bus
General I2C
bus error
7200,
3624, 3625
A7
7 Not applicable - - -
8 Not applicable
E/W Protection
(Large Screen)
7400,
3405,
3406, 3400
A2
9 M24C08
NVM I2C
identification
error
7602,
3611,
3603, 3604
A7
10 Tuner
Tuner I2C
identification
error
1000, 7482 A2, A4
11 TDA6107/8
Black current
loop protection
7330, RGB
amps, CRT
B1, B2
12 M65669
MAP I2C
identification
7803 P
Pa
g
