Mechanical Instructions
EN 10 TPT1.1HA LA4.
4.3.7 SSB and PSU cover removal
Refer to figure “SSB and PSU Cover removal” for details.
1. Remove the fixation screws [1].
2. Take of the cover.
Figure 4-9 SSB and PSU Cover removal
H_17010_101.eps
190907
1
1
1 1
1
1
1
1
