Alignments
EN 40 Q522.2HE LA6.
2010-Jun-30
Table 6-2 Tint settings
Note: Data of the 26" sets was not available at time of
publishing.
6.4 Option Settings
6.4.1 Introduction
The microprocessor communicates with a large number of I
2
C
ICs in the set. To ensure good communication and to make
digital diagnosis possible, the microprocessor has to know
which ICs to address. The presence / absence of these specific
ICs (or functions) is made known by the option codes.
Notes:
• After changing the option(s), save them by pressing the OK
button on the RC before the cursor is moved to the left,
select STORE in the SAM root menu and press OK on the
RC.
• The new option setting is only active after the TV is
switched “off” / “stand-by” and “on” again with the Mains
switch (the NVM is then read again).
6.4.2 Dealer Options
For dealer options, in SAM select “Dealer options” and then
“Personal options”.
Table 6-3 Dealer options
6.4.3 (Service) Options
Select the sub menu's to set the initialisation codes (options) of
the set via text menus.
6.4.4 Opt. No. (Option numbers)
Select this sub menu to set all options at once (expressed in
two long strings of numbers).
An option number (or “option byte”) represents a number of
different options. When these numbers are changed directly, all
options can be set very quickly. All options are controlled via
eight option numbers.
When the NVM is replaced, all options will require resetting. To
be certain that the factory settings are reproduced exactly, y
both option number lines have to be reentered. The correct
option numbers can be found on a sticker inside the TV set and
in Table 6-4
.
Example: The options sticker gives the following option
numbers:
• 41472 04109 06223 45160
• 10120 00098 00004 00000
The first line (group 1) indicates hardware options 1 to 4.
Example: option no. “2” contains the “cabinet type”.
The second line (group 2) indicates software options 5 to 8.
Example: option no. “5” contains the “display code”.
Every 5-digit number represents 16 bits (so the maximum value
will be 65536 if all options are set).
When all the correct options are set, the sum of the decimal
values of each Option Byte (OB) will give the option number.
See table Option code overview (subject to change and as
available at time of publishing) for the options. . Always refer to
the sticker in the TV-set as leading.
Diversity
Not all sets with the same Commercial Type Number (CTN)
necessarily have the same option code!
Use of Alternative BOM
An alternative BOM number usually indicates the use of an
alternative display. This results in another Display Code thus in
another Option code. Refer to chapter Precautions, Notes, and
Abbreviation List.
6.4.5 Option Code Overview
Table 6-4 Option code overview (subject to change and as available at time of publishing)
Important: After having edited the option numbers as
described above, the OK button has to be pressed on the
remote control before the cursor is moved to the left!
6.5 Reset of Repaired SSB
A very important issue towards a repaired SSB from a service
repair shop, implies the reset of the NVM on the SSB.
A repaired SSB in service should get the service Set type
“00PF0000000000” and Production code “00000000000000”.
Also the virgin bit is to be set. To set all this, the ComPair tool
can be used.
Colour Temp. R G B
32"
Cool 123 116 127
Normal 127 115 109
Warm 127 105 73
42"
Cool 127 105 121
Normal 127 98 99
Warm 127 85 63
Menu item Subjects Options Description
Personal Options Picture Mute On Picture is muted / not muted in case
no input signal is detected at input
connectors
Off
Virgin Mode On TV starts up / does not start up (once)
with a language selection menu after
the Mains switch is turned “on” for the
first time (virgin mode)
Off
CTN MODEL
Alt BOM Panel Type
Displ. code Group 1 Group 2
26HFL3350D/10
1 T260XW02-VM
168 41472 04109 06223 12328 08872 00101 00000 00000
26HFL3350D/10
2 LC260WXE-SBB1
214 41472 04109 06223 12328 08918 00101 00000 00000
26HFL5850D/10
1 T260XW02-VM
168 41472 04109 06351 12328 08872 00098 00000 00000
26HFL5850D/10
2 LC260WXE-SBB1
214 41472 36877 06351 12328 08918 00098 00000 00000
32HFL3350D/10
1 LC320WXN-SAB1
136 41472 04109 06223 12328 08840 00101 00000 00000
32HFL5850D/10
1 LC320WXN-SAB1
136 41472 04109 06351 12328 08840 00098 00000 00000
32HFL5850D/10
2 LC320WXE-SBA1
213 41472 36877 06351 12328 08917 00098 00000 00000
42PFL5850D/10
1 LC420WUE-SBA1
205 41474 36875 06351 12328 08909 00098 00000 00000
