Philips 32PFL3406D/78 - Page 97

Circuit Diagrams and PWB Layouts
EN 97L11M1.1L LA 10.
2011-Jun-24
back to
div. table
Layout
19131_017_110616.eps
110616
2011-01-12
5
2722 171 9027
IR/LED THRILLER
LAYOUT
D2
D1
R14
C4
C1
Q3
R7
R15
R13
U1
C3
ZD1
G1
Q1
Q2
R11
R12
R8
R9R10
R16
R17
R18
R3
R6
R22
R4
C2
RJ
GWA7.820.675-1A
8
11
3
C
J2
J1
2722 171 90275
XXXXXX-X0001
ZD2
Layout top
Layout bottom
