Alignments
EN 42 Q552.1L LA6.
2010-Dec-29
back to
div. table
Table 6-3 White D alignment values - LED - Minolta CS-200
If you do not have a color analyzer, you can use the default
values. This is the next best solution. The default values are
average values coming from production.
• Select a COLOUR TEMPERATURE (e.g. COOL,
NORMAL, or WARM).
• Set the RED, GREEN and BLUE default values according
to the values in Table 6-4
to Table 6-6.
• When finished press OK on the RC, then press STORE (in
the SAM root menu) to store the aligned values to the NVM.
• Restore the initial picture settings after the alignments.
Table 6-4 White tone default alignment setting van Gogh
Table 6-5 White tone default alignment setting da Vinci
Table 6-6 White tone default alignment setting Matisse
6.3.2 Ambilight
Every ambient light module is aligned by a matrix and by the
brightness. After replacement of a module, the brightness/color
must be aligned with the other modules:
1. Go to SAM.
2. Select “Alignments”.
3. Select “Ambilight”. A white test pattern shall be displayed
by the ambilight modules.
4. Select the number of the module that have to be aligned.
Module 1 is the first one which will come across according
the wiring path, starting at the small signal panel,
proceeding towards the ambient light modules.The first
module will be attached to the next module 2. Module
number 2 to number 3 etc..as follows the way to define the
ambilight module numbering.
5. Align the brightness compared with the neighboring
modules. The brightness is automatically stored.
6. Select one of 10 matrixes which color matches most with
the neighboring modules, “matrix 0” is the factory
alignment and can always be retrieved. (see table “6-7
Overview matrix correction table
7. The alignment is stored automatically.
Table 6-7 Overview matrix correction table
6.3.3 TCON/VCOM alignment
Sets with forward integration have the TCON on SSB. The
alignment of this TCON is stored in the SSB, and is related to
the used display. When an SSB or a display is replaced, a new
value must be entered.
A default value (see table below) is copied from the display file
(after entering the correct display code) and is shown in the
SAM menu. But on top of this, the default value can be
overruled manually via the menu item “TCON alignment”.
The current value is shown with 4 digits, and can be changed
by a digit entry. After pressing “OK”, the value is stored.
The menu item "Reset TCON alignment" can be used to return
to the default value from the display file. A notification is shown:
"TCON alignment has been reset".
Table 6-8 TCON default alignment setting van Gogh
Table 6-9 TCON default alignment setting da Vinci
Table 6-10 TCON default alignment setting Matisse
Note: 1). no TCON alignment required.
6.4 Option Settings
6.4.1 Introduction
The microprocessor communicates with a large number of I
2
C
ICs in the set. To ensure good communication and to make
digital diagnosis possible, the microprocessor has to know
which ICs to address. The presence / absence of these
PNX51XX ICs (back-end advanced video picture improvement
IC which offers motion estimation and compensation features
(commercially called HDNM) plus integrated Ambilight control)
is made known by the option codes.
Notes:
• After changing the option(s), save them by pressing the OK
button on the RC before the cursor is moved to the left,
select STORE in the SAM root menu and press OK on the
RC.
• The new option setting is only active after the TV is
switched “off” / “stand-by” and “on” again with the mains
switch (the NVM is then read again).
6.4.2 Dealer Options
For dealer options, in SAM select “Dealer options”.
Value Cool (11000K) Normal (9000K) Warm (6500K)
x 0.276 0.287 0.313
y 0.282 0.296 0.329
van Gogh 32PFL5615D 40PFL5615D 46PFL5615D
Colour Temp RGBRGBRGB
Normal 117 126 112 111 124 124 122 127 111
Cool 112 125 125 96 113 126 118 126 125
Warm 127 124 75 125 126 90 127 121 71
da Vinci 32PFL6615D 40PFL6615D 46PFL6615D
Colour Temp RGBRGBRGB
Normal 117 127 114 108 126 126 t.b.d. t.b.d. t.b.d.
Cool 112 126 126 92 113 127 t.b.d. t.b.d. t.b.d.
Warm 126 125 76 123 127 92 t.b.d. t.b.d. t.b.d.
Matisse 40PFL8605D 52PFL8605D
Colour Temp RGBRGBRGB
Normal 112 127 106 110 127 104
Cool 107 126 118 106 127 117
Warm 124 126 70 122 127 69
Matrix # fR fG fB
Matrix 0 1 1 1
Matrix 1 1 0.95 0.95
Matrix 2 0.95 1 0.95
Matrix 3 0.95 0.95 1
Matrix 4 0.95 1 1
Matrix 5 1 0.95 1
Matrix 6 1 1 0.95
Matrix 7 1 0.97 0.95
Matrix 8 0.97 0.95 1
Matrix 9 0.95 0.97 1
Panel Panel VCOM default
SHP
(Max:1023)
32 LED 106
40 LED 89
46 LED 132
Panel Panel VCOM default
SHP
(Max:1023)
32 LED 106
40 LED 89
46 LED 132
Panel Panel VCOM default
SHP
40 LED n.a.
1
52 LED n.a.
1
Matrix # fR fG fB
