Connecting to your PC
13
1 2
9
11
10
12
Fast Charger
RJ45
or
USB docking (USB C-C)
a-1
a-2
USB Type-C
OR
a
b
a
b
USB hub (USB A-C)
USB Type-A
a-1
a-2
OR
OR
a
b
c
USB A-B
a
b
USB hub
3
5
7
8
4
6
1
Power Switch
2
AC power input
3
HDMI 1 input
4
HDMI 2 input
5
DisplayPort input
6
USB C1
7
USB upstream
8
RJ45 input
9
USB downstream
10
USB downstream/USB fast charger
11
USB C2(Power supply up to 15W)
12
Audio (In/Out): audio out /
microphone in combo jack
13
Kensington anti-theft lock
Connect to PC
1. Connect the power cord to the back
of the display rmly.
2. Turn o your computer and unplug
its power cable.
3. Connect the monitor signal cable to
the video connector on the back of
your computer.
4. Plug the power cord of your
computer and your monitor into a
nearby outlet.
5. Turn on your computer and monitor.
If the monitor displays an image,
installation is complete.
