Philips 49PFL4909 - Stand Assembly; Attaching the Base

Stand Assembly
55PFL4909 / 50PFL4909 / 49PFL4909
1
2
× 4
49PFL4609
1
2
3
× 4
Attaching the Base
You must attach the base to the Unit to have it as a table top Unit.
Be sure the front and rear of the base match the proper direction. For
large screen TVs, at least 2 people are required for these steps.
55PFL4909 / 50PFL4909 / 49PFL4909 / 49PFL4609
1
2
× 4
40PFL4909
1
× 3
M4 x 0.787” (20mm)
2
2
1
9 .English
