Philips 5000 LATTE GO - CPU Board, EPSC Port, and Display Removal

PHI 5000 LATTE GO / GO+ 08 DISASSEMBLY
9/7
Loosen the screws for
remove the cover.
Disconnect the electrical
connections.
Remove the support KYB assy.
and disconnect the at cable.
7.15. KYB interface and display
Loosen the screws slide the
card off the support and
disconnect the electrical
connections.
Loosen the screw for
remove the cover.
7.13. CPU board
7.14. Programming access for Espresso Philips Service Center (EPSC)
