9.6 7272 series 55"
FOR ELECTRICAL PARTS/ASSEMBLIES SEE WIRING DIAGRAM CHAPTER 9
0030 Bezel
0040 Rear cover
0050R Stand_R
0050L Stand_L
0095 V0 SHEET
1050 Display panel
1053 Panel SSB
1054 Power Supply Unit
1056 IR/LED panel
1057 Keyboard control panel
1061 LED Modules
1062 LED Module
1068 LED Logo
1176 Remote control Not displayed
1184 Speakers
WiFi01 WiFi_USB
Pos No. Description Remarks
0040
1061
1061
1084
1184
0030
1068
1054
1050
1056
1057
0095
WIFI01
0050L
0050R
1053
1061
1062
