Philips BDP3000 - Page 40

8-2A
PARTS LIST: BDP3000/12
yt'QnoitpircseD.oN CN21.oN
1 996510025851 CD DOOR
1
11 996510025845 ASSY-PW BOARD
1
14 996510025835 BACK PLATE
1
15 996510031459 ASSY-MAIN BOARD
1
18 996510025849 TOP COVER
1
20 996510025832 BLU-RAY DISC MODULE 1
21 996510025842 ASSY-SW BOARD
1
6 996510025843 ASSY-FE BOARD
1
9 996510025846 BOTTOM PLATE
1
AVCABLE 996500020384 AUDIO/VIDEO CABLE 1
1
Assy1 996510025838 ASSY-FRONT PANEL
1
CN504 996510025841 8P CABLE SAN-8P P2.0 L130
1
J303 996510025852 4PIN CABLE TJC3-4Y*2
1
JP1 996510025834 CABLE 5P 130MM FH-JC20
1
JP2 996510025847 CABLE 6P 120MM FH-JC20
1
JP3 996510025844 4P CABLE 180MM
1
PAD 996510025837 SPONGE PAD
4
POWERCORD 996510001537 POWER CORD
1
RC 996510025848 REMOTE CONTROL
1
SATALINE 996510025836 HD TRANSMISSION LINE
1
SHIELDBOARD 996510025833 SHIELD BOARD
1
Screws List
yt'Q noitpircseD.oN CN21oN
8 S/T SCREW B 2.6 X 6 BF 6
66 X 3 B WERCS C/M ELGNAIRT01
4FB 8 X 3 B WERCS T/S21
13 1B6X3WERCSC/M
7FB 6 X 3B WERCS T/S61
2FB 6 X 3B W
ERCS T/S71
4 FB 7 X 3 B WERCS T/S91
SAFETY PRECAUTION
The parts identified by mark are critical for safety. Replace only with part
number specified.
The mounting position of replacement is to be identical with originals. The
substitute replacement parts which do not have the sam
Q208 996510026631 MOSFET AO3401 1
