8-2B
PARTS LIST: BDP3000/05
No. 12NC No. Description Q'ty
11 996510025845 ASSY-PW BOARD
1
14 996510025835 BACK PLATE
1
15 996510031457 ASSY-MAIN BOARD
1
18 996510026145 TOP COVER
1
20 996510025832 BLU-RAY DISC MODULE
1
21 996510025842 ASSY-SW BOARD
1
6 996510025843 ASSY-FE BOARD
1
9 996510025846 BOTTOM PLATE
1
AVCABLE 996500020384 AUDIO/VIDEO CABLE 1.5M
1
Assy1 996510025838 ASSY-FRONT PANEL
1
CN504 996510025841 8P CABLE SAN-8P P2.0 L130
1
DBOX 996510026146 DISPLAY BOX
1
J303 996510025836 HD TRANSMISSION LINE
1
JP1 996510025834 CABLE 5P 130MM FH-JC20
1
JP2 996510025847 CABLE 6P 120MM FH-JC20
1
JP3 996510025844 4P CABLE 180MM
1
PAD 996510025837 SPONGE PAD
4
POWERCORD 996510026331 POWER CORD
1
PWRSKT 996510026144 POWER SUPPLY SOCKET
1
RC 996510025848 REMOTE CONTROL
1
TWISTTIE 996510026143 TWIST TIE NY66
1
Screws List
No 12NC No. Description Q'ty
8 S/T SCREW B 2.6 X 6 BF 6
10 TRIANGLE M/C SCREW B 3 X 6 6
12 S/T SCREW B 3 X 8 BF 4
13 M/C SCREW 3 X 6 B 1
16 S/T SCREW B3 X 6 BF 7
17 S/T SCREW B3 X 6 BF 2
19 S/T SCREW B 3 X 7 BF 4
SAFETY PRECAUTION
The parts identified by mark are critical for safety. Replace only with part number
specified.
The mounting position of replacement is to be identical with originals. The substitute
replacement parts which do not have the sam
Q208 996510026631 MOSFET AO3401
