Philips Brilliance BDM3470UP - MultiView Input and Display Options

11
2. Setting up the monitor
• PiP / PbP Input: There are four different
video input to choose as the sub display
source: [DVI], [HDMI], and [DisplayPort].
Please refer below table for compatibility
of main/sub input source.
SUB SOURCE
POSSIBILITY (xl)
Inputs VGA DP DVI HDMI
MAIN
SOURCE
(xl)
VGA ● ● ●
DP ● ● ●
DVI ● ● ●
HDMI ● ● ●
• PiP Size: When PiP is activated, there are
three sub-window sizes to choose: [Small],
[Middle], [Large].
B
A (main)
Small
Middle
Large
• PiP Position: When PiP is activated, there
are two sub-window positions to choose.
Top-Right Bottom-Right
B
A (main)
A (main)
B
• Swap: The main picture source and the
sub picture source swapped on the
display.
Swap A and B source in [PiP] mode:
B
A (main)
↔
B (main)
A
Swap A and B source in [PbP] mode:
A (main)B
↔
B (main)A
• Off: Stop MultiView function.
A (main)
Note
• When you do the SWAP function, the
video and its audio source will swap
at the same time. (Refer to page 7
“Independent audio playback, regardless of
video input”formoredetail.)
• DisplayPort supports resolution to only
3440 x 1440 @ 30 Hz when in PBP mode
or when it is the sub source in PIP mode; it
supports resolution to 3440 x 1440 @ 60
Hz when it is the main source in PIP mode.
