Philips BTM2360/ALL - Dismantling Instructions; Top Cabinet Dismantling; PCB Board Dismantling

b: Remove 9 screws D as indicated to loosen the display board
6.DISMANTING DIAGRAM
1)Dismanting of the top cabinet:Remove 10 screws A&B as indicated to loosen the top cabinet
2)Dismanting of the PCB board:
a: Remove 7 screws C as indicated to loosen the main board
D
A
B
C
