Philips CARDIOMD - Collimators; Gantry

Spare Parts
1MAN0158-H11 04-2005 CSIP Level 1 CardioMD Service Manual  9-3
Philips part no. DDD part no. Description System
series
Qty per
system
DDD2PMT0096A 2PMT0096-A OPTICAL COUPLING COMPOUND I, II, III NA
9.1.2 Collimators
Philips part no. DDD part no. Description System
series
Qty per
system
DDD9CSY0847D 9CSY0847-D LEHR COLLIMATOR I, II 2
DDD9CSY1281A 9CSY1281-A LEHR COLLIMATOR III 2
DDD9CSY0846D 9CSY0846-D LEGP COLLIMATOR I, II Option
DDD9CSY1280A 9CSY1280-A LEGP COLLIMATOR III Option
2163-5445 9COL0888-A COLLIMATOR ID BOARD I, II, III 2
2163-3055A 9CSY0910-A COLLIMATOR CABINET I, II Option
DDD9CSY1377A 9CSY1377-A COLLIMATOR CABINET III Option
DDD4CSY1271B 4CSY1271-B COLLISION PAD FOR COLLIMATOR I, II 2
DDD4CSY1756A 4CSY1756-A COLLISION PAD FOR COLLIMATOR III 2
9.1.3 Gantry
Philips part no. DDD part no. Description System
series
Qty per
system
2163-5421 9UNF0643-A POWER SUPPLY (MAINS UNIT) I, II, III 1
2163-5420 9CSA0865-A SAFETY BOARD I, II, III 1
2163-5417 9MOT0918-B TWO AXES MOTOR CONTROLLER I, II, III 2
2163-5415 9CTA0858-A TABLE DRIVE BOARD I, II, III 1
DDD9KIT1305B 9KIT1305-B ROLL/Y MOTOR AMPLIFIER INST. KIT I, II, III NA
2163-5457 9AMP0924-A X MOTOR AMPLIFIER I, II, III 1
DDD9SER1354A 9SER1354-A X-DRIVE BEARING KIT I, II, III NA
2163-5478 2MOT1270-A ROLL/Y HDD MOTOR I, II, III 2
2163-5453 9CSY0987-A X MOTOR (dunker motor) I, II, III 1
2163-5452 2MOT0990-A TABLE MOTOR I, II, III 1
2163-5493 9CBL0881-A ABS POSITION ENCODER I, II, III 3
DDD4CSY1293A 4CSY1293-A KEY PLATE INCL. HARDWARE I, II, III 1
2163-5416 9CSY0761-A SIDE CONNECTOR PANEL I, II 1
DDD9CSY1382A 9CSY1382-A SIDE PANEL III 1
DDD9PAN1462A 9PAN1462-A INTERNAL CONNECTOR PANEL III 1
DDD9CBL0946A 9CBL0946-A E-STOP CABLE, SHORT III 1
DDD3HUB1732A 3HUB1732-A FIREWIRE HUB III 1
DDD9CBL1443A 9CBL1443-A FIREWIRE HUB POWER CABLE III 1
DDD9PAN1460A 9PAN1460-A REAR CONNECTOR PANEL III 1
2163-5494 9CBL0882-A ULTIMATIVE STOP SWITCH I, II, III 3
2163-5495 9CBL0883-A ULTIMATIVE STOP CABLE I, II, III 3
2163-5480 9CBL0531-A HDD RESOLVER CABLE I, II, III 2
2163-5473 9CBL0895-A DUAL INPUT CABLE I, II, III 1
2163-5474 9CBL0896-A DUAL OUTPUT CABLE I, II, III 1
