Philips CARDIOMD - Side Panel

Detailed Description
1MAN0158-H11 04-2005 CSIP Level 1 CardioMD Service Manual  3-17
Figure 3.12 Connector panel on rear of table console (CardioMD Series III)
3.2.5.2 Side Panel
External
As shown in Figure 3.13, one E-Stop button is located on the side of the table console.
Figure 3.13 E-Stop button on side of table console (CardioMD Series III)
PC and ECG gate
power indicator
PC and ECG gate
fuse reset button
Mains power
cable
ECG
trigger
System power
on/off switch
LAN
connection
ECG gate
power cable
III
