Philips DCM3065/51 - Overview of the Main Unit

8 EN
Overview of the main unit
a
• Turn on the unit, or switch to standby
mode, or switch to Eco Power standby.
b SOURCE
• Select a source: CD, FM radio, iPod/
iPhone/iPad, USB, or MP3 link.
c
/
• Skip to the previous/next track.
• Search within a track.
• Tune to a radio station.
d
/OK
• Start or pause play.
• Conrm a selection.
e
/MENU
• Stop play.
• Access the iPod/iPhone/iPad menu.
f VOLUME + / -
• Adjust volume.
g
• Open/close the disc compartment.
MP
3
-
LINK
FM ANT
lmn
k
d
e
f
g
o
h
i
j
h Display panel
• Show current status.
i Disc compartment door
j Dock for iPod/iPhone/iPad
k Remote sensor
• Detect signal from the remote control.
l
• Connector for a headphone.
m
• Connector for a USB mass storage
device.
n MP3 LINK
• Connector (3.5mm ) for an external
audio device.
o FM ANT
• Connect an FM antenna for reception
improvement.
