1-1
TECHNICAL SPECIFICATION
General
Dimensions : 435 x 100 x 370mm
Net weight : 7.0kg
Power Supply /22S : 230V ±10%, 50Hz
Power consumption Standby : ≤0.5W
DAB Tuner
Tuning range : 174-240MHz (Band III)
1452-1492MHz (L)
AM Tuner
Tuning range /22S : 531-1602kHz, 9kHz grid
Tuning range /37 : 530-1700kHz, 10kHz grid
IF : 450kHz
Sensitivity (26dB S/N) : ≤3250µV/m (2000µV/m)
Distortion (rf=1mV, m=80%) : ≤5% (4% typ.)
FM Tuner
Tuning range /22S : 87.5-108MHz, 50kHz grid
Tuning range /37 : 87.5-108MHz, 100kHz grid
IF : 10.7MHz
Sensitivity (26dB S/N) : ≤22dBf (15dBf typ.)
-3dB limiting point : ≤23.5dBf (10dBf typ.)
Distortion (rf=1mV, m=80%) : ≤3% (0.23% typ.)
Crosstalk (rf=1mV, ∆f=75kHz) : ≤-26dB (-48dB typ.)
Video performance – Composite Video
Signal level : 1Vpp (75Ω)
Frequency response : 0-6MHz
S/N ratio : >50dB
Video performance – S-Video
Signal level Y : 1Vpp (75Ω)
Signal level C : 0.286Vpp (75Ω)
Frequency response : 0-6.5MHz
S/N ratio : >65dB
Video performance – Component Video / RGB
Signal level Y : 1Vpp (75Ω)
Signal level PB/CB, PR/CR : 0,7Vpp (75Ω)
Signal level R/G/B : 0,7Vpp (75Ω)
Frequency response : 0-7MHz
Frequency resp. progressive : 0-16MHz
S/N ratio : >70dB
Video input resolutions/formats
PAL 576i (720 x 576i)
PAL progressive 576p (720 x 576p, downscaled to 576i)
NTSC 480i (720 x 480i)
NTSC progressive 480p (720 x 480p, downscaled to 480i)
Video output resolutions/formats
PAL input 50Hz (TV) : 576i (720 x 576i)
576p (720 x 576p)
720p (1280 x 720p)
1080i (1920 x 1080i)
NTSC input 60Hz (TV) : 480i (720 x 480i)
480p (720 x 480p)
720p (1280 x 720p)
1080i (1920 x 1080i)
Digital video input/output
PAL input 50Hz (TV) : 576i (720 x 576i)
576p (720 x 576p)
720p (1280 x 720p)
1080i (1920 x 1080i)
NTSC input 60Hz (TV) : 480i (720 x 480i)
480p (720 x 480p)
720p (1280 x 720p)
1080i (1920 x 1080i)
PC input 60Hz : VGA (640 x 480p)
SVGA (800 x 600p)
XGA (1024 x 768p)
SXGA (1280 x 1024p)
Audio Line-in
Input sensitivity : 0.2-2.8Vrms
Input impedance : 22kΩ
Audio Line/Rec Out
Output voltage : 1.6Vrms
Outut impedance : 1kΩ
Frequency response : 5Hz-100kHz
S/N ratio : 110dBA typ.
THD (1kHz, 1W) : ≤0.0016%
Power amplifier
Output power (1kHz, THD=1%): 2 x 110W RMS into 4Ω
6 x 65W RMS into 4Ω
Frequency response (1W) : 5Hz-45kHz
S/N ratio : 105dBA typ.
THD (1kHz, 1W) : ≤0.065%
ADC/DAC
Resolution : 24bits/96kHz
Digital In/Out
Coaxial input : 0.2Vpp, 75Ω
Coaxial output : 0.5Vpp, 75Ω
Supported multichannel formats
Dolby ProLogic IIx, Dolby Digital, Dolby Digital EX, DTS,
DTS 96/24, DTS ES Matrix, DTS ES Discret, DTS NEO:6
