DVD616K IFU for /751 3141 016 18911
PLAYBACK SYSTEM
DVD Video
Video CD & SVCD
CD (CD-Recordable and CD-Rewritable)
Picture CD
MP3 CD
CD-R, CD-RW
DVD-R, DVD+RW
VIDEO PERFORMANCE
* CVBS 1Vpp --- 75Ω
* S-VIDEO Y: 1.00Vpp --- 75Ω
C: 0.30Vpp --- 75Ω
* YUV Y: 1.00Vpp --- 75Ω
CR: 0.7Vpp --- 75Ω
CB: 0.7Vpp --- 75Ω
AUDIO FORMAT
Digital Mpeg/ AC-3/ DTS compressed Digital
PCM 16, 20, 24 bits
fs, 44.1, 48, 96 kHz
MP3(ISO 9660) 24, 32, 56, 64, 96, 128,
256 kbps & variable
bit rate fs, 16, 22.05,
24, 32, 44.1, 48 kHz
Analog Sound Stereo
Dolby Digital multichannel surrond sound downmix 2
channels.
AUDIO PERFORMANCE
DA Converter 24bit
Signal-Noise (1KHz) 90dB
Dynamic range(1KHz) 80dB
DVD fs 96 kHz 4Hz- 44kHz
fs 48 kHz 4Hz-22kHz
SVCD fs 48 KHz 4Hz-22kHz
fs 44.1 kHz 4Hz-20kHz
VCD/CD fs 44.1 kHz 4Hz- 20 KHz
TV STANDARD (PAL/50Hz) (NTSC/60Hz)
Number of lines 625 525
Playback Multistandard (PAL/NTSC)
CONNECTIONS
YUV Video Output Cinch
S-Video Output Mini DIN 4-pins
Video Output Cinch
Audio Output(L+R) Cinch
Digital Output 1 coaxial / optical
IEC958 for CDDA / LPCM/ MPEG1
IEC1937 for MPEG 2, Dolby
Digital and DTS
CABINET
Dimensions (w x d x h) 435 x 235 x 71 mm
Weight Approximately 2.5 Kg
Specifications subject to change without prior notice
Specifications
Cleaning the Cabinet
¶ Use a soft cloth slightly moistened with a mild
detergent solution. Do not use a solution
containing alcohol, spirits, ammonia or abrasives.
Cleaning Discs
¶ When a disc becomes dirty, clean it with a
cleaning cloth. Wipe the disc from the center out.
Do not wipe in a circular motion.
¶ Do not use solvents such as benzine, thinner,
commercially available cleaners, or antistatic spray
intended for analog records.
Maintenance
