Philips EP Series Service Manual

 
Philips EP Series
Level  (Start test mode)
Level  (Keys, Buzzer, Leds)
Test Mode Omnia 0-1-2-3
nomeFile
20181030_TestMode_
Omnia_0-1-2-
3_230V_v05
1 Nicola Laffi 2-nov-18 5/16
revNum Redatto Verificato Approvato SaveDate Pagina/pagine
Press button B3
(only 2A)
L3(O) & L4(O) ON
L4 OFF
L4 damaged Change UI boad
L4
(!O
) ON
L4 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B3 (optional) L3 & L4 OFF
Press button B5
L7(O) ON
L7 OFF
L7 damaged Change UI boad
L7(!O) ON
L7 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B5 (optional) L7 OFF
Press button B7
(only 3B&3C)
L10(O) ON
L10 OFF
L10 damaged Change UI boad
L10(!O) ON
L10 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B7 (optional) L10 OFF
Press button B8
L11(O) ON
L11 OFF
L11 damaged Change UI boad
L11(!O) ON
L11 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B8
L11(O) & L12(O)
ON
L12 OFF
L12 damaged Change UI boad
L12(!O) ON
L12 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B8
L11(O) & L12(O)
& L13(O) ON
L13 OFF
L13 damaged Change UI boad
L13
(!O
) ON
L13 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B8
L11(O) & L12(O)
& L13(O) &
L14(O) ON
L14 OFF
L14 damaged Change UI boad
L14(!O) ON
L14 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B8 (optional) L11 & L12 & L13
& L14 OFF
Press button B9
L15(O) ON
L15 OFF
L15 damaged Change UI boad
L15(!O) ON
L15 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B9
L15(O) & L16(O)
ON
L16 OFF
L16 damaged Change UI boad
L16(!O) ON
L16 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B9
L15(O) & L16(O)
& L17(O) ON
L17 OFF
L17 damaged Change UI boad
L17
(!O
) ON
L17 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B9 (optional) L15 & L16 & L17
OFF
Press button B10
(only 3B&3C)
L21(O) ON
L21 OFF
L21 damaged Change UI boad
L21(!O) ON
L21 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B10
(only 3B&3C)
L21(O) & L22(O)
ON
L22 OFF
L22 damaged Change UI boad
L22(!O) ON
L22 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Test mode
Test Mode Omnia 0-1-2-3
nomeFile
20181030_TestMode_
Omnia_0-1-2-
3_230V_v05
1 Nicola Laffi 2-nov-18 4/16
revNum Redatto Verificato Approvato SaveDate Pagina/pagine
1.1 Level 0 (Start Test mode)
Start condition: NO BU, NO drag drawer,
Door open, No Water
LED INDICATION
L1 and L2 Blink Alternately
1.2 Level 1 (Keys, Buzzer, Leds)
Start condition: NO BU, NO drag drawer,
Door open, No Water
LED INDICATION
All Leds OFF
Sequence of actions by user Reaction of the appliance
PASS FAIL
Cause of failure
Solution
Press button B2
L1(O) ON,
It’s
possible to hear
the feedback
sound.
L1 OFF
L1 damaged Change UI boad
L1(!O) ON
L1 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
It’s not possible
to hear the
sound
The drive of the
Buzzer or the
Buzzer in the Main
is damaged
Change Main Board
The sound is
persistent
The drive of the
Buzzer or the
Buzzer in the Main
is damaged
Change Main Board
Press button B2
L1(O) & L2(O) ON
L2 OFF
L2 damaged Change UI boad
L2
(!O
) ON
L2 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B2 (optional) L1 & L2 OFF
Press button B4
L5(O) ON
L5 OFF
L5 damaged Change UI boad
L5(!O) ON
L5 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B4
L5(O) & L6(O) ON
L6 OFF
L6 damaged Change UI boad
L6(!O) ON
L6 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B4 (optional) L5 & L6 OFF
Press button B6
(only 3B&3C)
L8(O) ON
L8 OFF
L8 damaged Change UI boad
L8(!O) ON
L8 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B6
(only 3B&3C)
L8(O) & L9(O) ON
L9 OFF
L9 damaged Change UI boad
L9(!O) ON
L9 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B6 (optional) L8 & L9 OFF
Press button B3
L3(O) ON
L
3
OFF
L3 damaged Change UI boad
L3
(!O
) ON
L3 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Test Mode Omnia 0-1-2-3
nomeFile
20181030_TestMode_
Omnia_0-1-2-
3_230V_v05
1 Nicola Laffi 2-nov-18 4/16
revNum Redatto Verificato Approvato SaveDate Pagina/pagine
1.1 Level 0 (Start Test mode)
Start condition: NO BU, NO drag drawer,
Door open, No Water
LED INDICATION
L1 and L2 Blink Alternately
1.2 Level 1 (Keys, Buzzer, Leds)
Start condition: NO BU, NO drag drawer,
Door open, No Water
LED INDICATION
All Leds OFF
Sequence of actions by user Reaction of the appliance
PASS FAIL
Cause of failure
Solution
Press button B2
L1(O) ON,
It’s
possible to hear
the feedback
sound.
L1 OFF
L1 damaged Change UI boad
L1(!O) ON
L1 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
It’s not possible
to hear the
sound
The drive of the
Buzzer or the
Buzzer in the Main
is damaged
Change Main Board
The sound is
persistent
The drive of the
Buzzer or the
Buzzer in the Main
is damaged
Change Main Board
Press button B2
L1(O) & L2(O) ON
L2 OFF
L2 damaged Change UI boad
L2
(!O
) ON
L2 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B2 (optional) L1 & L2 OFF
Press button B4
L5(O) ON
L5 OFF
L5 damaged Change UI boad
L5(!O) ON
L5 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B4
L5(O) & L6(O) ON
L6 OFF
L6 damaged Change UI boad
L6(!O) ON
L6 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B4 (optional) L5 & L6 OFF
Press button B6
(only 3B&3C)
L8(O) ON
L8 OFF
L8 damaged Change UI boad
L8(!O) ON
L8 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B6
(only 3B&3C)
L8(O) & L9(O) ON
L9 OFF
L9 damaged Change UI boad
L9(!O) ON
L9 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Press button B6 (optional) L8 & L9 OFF
Press button B3
L3(O) ON
L
3
OFF
L3 damaged Change UI boad
L3
(!O
) ON
L3 wrong color Change UI boad
Other Lx toggle
Short circuit in Leds
or Buttons
Change UI boad
Test mode

Philips EP Series Specifications

General

Capacity	1.8 L
Grinder Type	Ceramic
Number of Grinder Settings	12
Pump Pressure	15 bar
Adjustable Aroma Strength	Yes
Adjustable Coffee Volume	Yes
Adjustable Milk Volume	Yes
Auto Shut-off	Yes
Keep Warm Function	Yes
Removable Filter Basket	Yes
Water Level Indicator	Yes
Voltage	230 V
