Philips EP Series Service Manual

 
Philips EP Series
Before you start dismantling!
For your safety be sure the plug is disconnected from the mains!
The product is designed for easy access to the internal components. Make sure that
all accessories have been removed.
Removal of the housing:
. Make sure the power cable is unplugged.
. Take out the four screws and pull up the upper cover.
. When assemby the nger-protection screw:
• Up to SN TW901907111749 use torque force 1.2Nm +/- 0.1
• From SN TW901907111750 use torque force 0.8Nm +/- 0.1
. Take out the two screws in the back panel and remove it.
. To remove the two laterals panel take out  screws for each of them
Disassembly - and Reassembly advice Disassembly - and Reassembly advice

Philips EP Series Specifications

General

Capacity	1.8 L
Grinder Type	Ceramic
Number of Grinder Settings	12
Pump Pressure	15 bar
Adjustable Aroma Strength	Yes
Adjustable Coffee Volume	Yes
Adjustable Milk Volume	Yes
Auto Shut-off	Yes
Keep Warm Function	Yes
Removable Filter Basket	Yes
Water Level Indicator	Yes
Voltage	230 V
