Philips EP Series

Removal of the UI

. To remove the UI push the  snaps inside (indicated with the red arrows):

. Then unplug the cable.

Do not use a screwdriver, but pull it keeping the at cable and not the connector (some force is required)

. Click on the  snaps to remove the UI board protection.

. To re-mount the UI start keeping inserted rst the upper part of the cover, then push it.

Make sure the  snaps are properly closed

Removal of the Grinder

. Pull out the grinder assy

. Remove the electric connections

Removal of the Electrovalves

. For the upper EV pull outwards the valve holder.

. For the lateral EV take out the  screws, then remove the valve.

Disassembly - and Reassembly advice Disassembly - and Reassembly advice
