Philips FR975 - Page 53

9-5
ELECTRICAL PARTSLIST - MAINS BOARD
MISCELLANEOUS
PCS 105 723
1051 4822 267 31994 MAINS OUTLET only in /00/01C
1053 4822 267 31994 MAINS OUTLET only in /00/01C
1054 2422 030 00301 MAINS OUTLET only in /17
1055 4822 272 10269 VOLTAGE SEL. only in /01C
1056 4822 276 13224 MAINS SWITCH
1061 4822 265 20723 MAINS INLET
1062 4822 280 10391 RELAY
1063 4822 267 10728 B4P7-VH only in /01C
1064 4822 265 20723 B2P3-VH
1065 4822 071 54002 FUSE 4A only in /01C
1066 4822 071 54002 FUSE 4A only in /00/01C
1066 4822 071 55002 FUSE 5A only in /17
1067 2422 086 10912 FUSE 2,5A only in /00
1067 2422 086 10915 FUSE 5A only in /01C
1068 4822 071 52001 FUSE 200MA only in /01C
1069 4822 071 53151 FUSE 315MA only in /00/17
1078 4822 071 51602 FUSE 1.6A
1079 4822 071 52002 FUSE 2A
2051 4822 121 43526 47NF 5% 250V
2052 4822 121 43526 47NF 5% 250V
2053 4822 124 40207 100UF20% 25V only in /01C
2054 4822 124 40207 100UF20% 25V only in /01C
2055 4822 126 14084 4,7NF 20% 250V
3051 4822 053 21106 10M only in /17
3052 4822 050 11002 1K00 1% 0,4W
3053 4822 050 11002 1K00 1% 0,4W
3054 4822 116 52283 4K7 5% 0,5W only in /01C
3055 4822 116 52256 2K2 5% 0,5W only in /01C
3056 4822 050 21003 10K 1% 0,6W only in /01C
3057 4822 052 10129 12R00 5% 0,33W
3058 4822 116 52256 2K2 5% 0,5W
3059 4822 050 21003 10K00 1% 0,6W
3061 4822 050 21003 10K00 1% 0,6W
3079 4822 052 10108 1R 5% 0,33W only in /01C
5052 4822 146 11143 STBY TRAFO for /00
5052 4822 146 11144 STBY TRAFO for /01C
5052 4822 146 11142 STBY TRAFO for /17
6051 4822 130 30621 1N4148
6052 4822 130 31878 1N4003G
6053 4822 130 31878 1N4003G
6055 4822 130 31878 1N4003G
6056 4822 130 31878 1N4003G
6057 4822 130 30621 1N4148
6058 4822 130 30621 1N4148
6059 4822 130 31878 1N4003G only in /01C
6060 4822 130 31878 1N4003G only in /01C
6061 4822 130 34382 BZX79-B8V2 only in /01C
6062 4822 130 30621 1N4148
6063 4822 130 30621 1N4148
6064 4822 130 30621 1N4148
6065 4822 130 31878 1N4003G only in /01C
6066 4822 130 30621 1N4148
6067 4822 130 30621 1N4148
7051 4822 130 41246 BC327-25 only in /01C
7052 4822 130 40959 BC547B only in /01C
7053 4822 130 40981 BC337-25
CAPACITORS
RESISTORS
TRAFO
DIODES
TRANSISTORS
DIODES
