Philips FR975 - Page 68

1260 4822 252 51123 FUSE6,3A
1261 4822 252 51123 FUSE 6,3A
1301 2422 015 19403 SCREW 6P LS
1502 4822 267 31823 CINCH
1512 4822 267 31823 CINCH
1513 4822 267 31823 CINCH
1514 4822 267 31823 CINCH
1516 4822 267 31823 CINCH
1520 4822 265 10981 CINCH 1P
1521 2422 025 11067 CON BM V 12P
1523 2422 025 11067 CON BM V 12P
1525 4822 265 11608 CINCH 2P
1540 4822 265 20542 CINCH 2P
1542 2422 026 05134 CINCH 2P
1550 4822 267 31729 CINCH 1P
1801 4822 267 31996 CONN. 1P
1802 4822 265 11619 CINCH 2P
1803 4822 265 11619 CINCH 2P
1901 4822 265 11609 CON. CLICK 4P
2251 5322 121 42578 100NF 5% 250V
2253 4822 121 43526 47NF 5% 250V
2254 5322 121 42578 100NF 5% 250V
2256 4822 121 43526 47NF 5% 250V
2257 4822 122 33177 10NF 20% X7R 50V
2259 4822 124 80415 4700UF20% 50V
2260 4822 124 80415 4700UF20% 50V
2262 4822 124 12423 4700UF 20% 63V
2264 4822 124 12423 4700UF 20% 63V
2266 5322 121 42386 100NF 5% 63V
2267 4822 124 41751 47UF 20% 50V
2268 5322 121 42386 100NF 5% 63V
2269 4822 124 80563 4700UF 35V
2270 4822 126 13838 100NF 50V P80M20
2271 4822 126 14583 470NF 10% 16V
2272 4822 124 12328 6800UF 16V
2273 4822 126 14585 100NF 10% 50V
2274 4822 126 14583 470NF 10% 16V
2275 4822 124 81144 1000U 16V
2276 4822 126 14585 100NF 10% 50V
2277 4822 126 14583 470NF 10%
2278 4822 124 22652 2,2UF20% 50V
2279 4822 126 14585 100NF 10% 50V
2280 4822 124 41584 100UF 20% 10V
2281 4822 126 13838 100NF 50V P80M20
2282 4822 126 14583 470NF 10% 16V
2290 4822 124 40248 10UF20% 63V
2295 4822 122 33177 10NF 20% X7R 50V
2298 5322 122 32654 22NF10%X7R 63V
2299 5322 124 40641 10UF 20% 100V
2301 5322 122 32654 22NF10%X7R 63V
2303 4822 124 40764 22UF 100 V
2305 5322 124 40641 10UF 20% 100V
2306 4822 124 40248 10UF20% 63V
2308 5322 122 32448 10PF 5% NP0 63V
2309 5322 122 32448 10PF 5% NP0 63V
2310 4822 124 40248 10UF20% 63V
2311 5322 122 32268 470PF 10% 50V
2313 4822 122 33575 220PF 5% NP0 63V
2314 4822 126 13473 220NF80-20% 50V
2315 4822 124 40433 47UF 20% 10V
2316 4822 124 40248 10UF20% 63V
2319 5322 122 32268 470PF 10% 50V
2321 4822 126 13473 220NF80-20% 50V
14-1
ELECTRICAL PARTSLIST - MONO2 BOARD
PCS 105 736
CAPACITORS
MISCELLANEOUS
CAPACITORS
2325 4822 122 33575 220PF 5% NP0 63V
2326 5322 122 32448 10PF 5% NP0 63V
2327 5322 122 32448 10PF 5% NP0 63V
2330 4822 124 40433 47UF 20% 10V
2333 4822 126 13473 220NF80-20% 50V
2334 4822 124 40248 10UF20% 63V
2337 5322 122 32268 470PF 10% 50V
2341 4822 122 33575 220PF 5% NP0 63V
2345 5322 122 32448 10PF 5% NP0 63V
2346 4822 124 40433 47UF 20% 10V
2348 5322 122 32448 10PF 5% NP0 63V
2349 4822 124 40248 10UF20% 63V
2350 4822 124 40181 220UF20% 10V
2353 4822 124 40764 22UF 100 V
2354 5322 124 40641 10UF 20% 100V
2357 4822 126 12882 100NF+80-20% 50V
2358 4822 126 13473 220NF80-20% 50V
2359 4822 126 13473 220NF80-20% 50V
2360 4822 126 13473 220NF80-20% 50V
2365 4822 121 41857 10NF 5% 250V
2371 5322 126 10223 4,7NF10%X7R 63V
2372 5322 126 10223 4,7NF10%X7R 63V
2373 5322 126 10223 4,7NF10%X7R 63V
2374 5322 122 32531 100PF 5%NP0 50V
2375 5322 122 32531 100PF 5%NP0 50V
2376 5322 122 32531 100PF 5%NP0 50V
2501 5322 126 10511 1NF 5%NP0 50V
2502 5322 126 10511 1NF 5%NP0 50V
2505 5322 126 10511 1NF 5%NP0 50V
2506 5322 126 10511 1NF 5%NP0 50V
2507 5322 126 10511 1NF 5%NP0 50V
2508 5322 122 32531 100PF 5%NP0 50V
2509 5322 122 32531 100PF 5%NP0 50V
2510 5322 122 32531 100PF 5%NP0 50V
2511 5322 122 32531 100PF 5%NP0 50V
2512 5322 122 32531 100PF 5%NP0 50V
2513 5322 122 32531 100PF 5%NP0 50V
2514 5322 122 32531 100PF 5%NP0 50V
2515 5322 122 32531 100PF 5%NP0 50V
2516 5322 122 32531 100PF 5%NP0 50V
2517 5322 122 32531 100PF 5%NP0 50V
2518 5322 122 32531 100PF 5%NP0 50V
2519 5322 122 32531 100PF 5%NP0 50V
2520 5322 122 32531 100PF 5%NP0 50V
2521 5322 122 32531 100PF 5%NP0 50V
2522 5322 122 32531 100PF 5%NP0 50V
2523 5322 122 32531 100PF 5%NP0 50V
2524 5322 122 32531 100PF 5%NP0 50V
2525 5322 122 32531 100PF 5%NP0 50V
2526 5322 122 32531 100PF 5%NP0 50V
2527 4822 124 41751 47UF 20% 50V
2528 4822 124 41751 47UF 20% 50V
2529 4822 126 13838 100NF 50V P80M20
2530 4822 126 13838 100NF 50V P80M20
2531 4822 121 42408 220NF 5% 63V
2532 4822 121 42408 220NF 5% 63V
2533 4822 124 81151 22UF 50V
2534 4822 124 81151 22UF 50V
2535 4822 124 81151 22UF 50V
2536 4822 124 81151 22UF 50V
2537 4822 124 81151 22UF 50V
2538 4822 124 81151 22UF 50V
2539 4822 124 40207 100UF20% 25V
2540 4822 124 40433 47UF20% 25V
2541 4822 124 40248 10UF20% 63V
