Philips FX20 - Technical Specifications; Power Supply; Surge Immunity (Lightning Test)

Reference: WX-B-009-01
Title: Product Performance
Specification
Rev./Status: 0.2 / Draft
Model : FX20 FX30 FX50 Page 10 of 19
-
FX20 FX30 FX50
Mini Audio system
- 2013-12-09
2 - 2014-02-28
3
NAME
Suhaofeng/Tangbing 19 10 - 10 A4
CHECK DATE
2014-02-28
3. Technical Specifications
3.1 Power Supply
3.1.1 Type and versions
3.1.1.1 Main set
Build-inSMPS will be used for all models and stroke versions.
Versions Region/Country SMPS Detachable mains cords
10 EUROPE / UK
230~240Vac nom.
Frequency: 50Hz.
EU (/12) round 2-pin & UK (/05) 3-pin
37 NAFTA
90~132Vac limit.
Frequency: 60Hz.
UL flat pin (polarized)
FX20/55
FX30/55
LATAM
90~240Vac
Frequency: 50/60Hz.
INMETRO certified round 2-pin
FX30/55
FX50/55
LATAM
90~132Vac & 220-240Vac
selectable
Frequency: 50/60Hz.
INMETRO certified round 2-pin
98 APAC
90~132Vac & 220-240Vac
selectable
Frequency: 50/60Hz.
EU round 2-pin
94 India
2) 100 ~310Vac limit (India
compatible with up cost) used
only for India.
Frequency: 47~63Hz.
EU (/12) round 2
-pin
All requirements per defined for each country should be met with sufficient testing.
3.1.2 Surge Immunity (Lightning Test)
The product shall withstand mains interference’s of:
Differential mode:
• 2kV/2 ohm criteria C for Europe.
• 6kV/12 ohm criteria C for NAFTA.
Parameters:
• Bi-wave
• Open circuit voltage: 2/50us
• Short circuit current: 8/20us
• From +/1kV to +/-2kV (for Europe) or +/-6kV (for Nafta) in steps of 1kV.
• 10 shots per combination.
2-7
