21. Assemble Tray Assy 13, assemble Screw G, fasten Screw G
22. Assemble Screw I, fasten Screw I
23. Assemble Rinse Bush Assy 15
24. Assemble Rinse Cap Assy 14
25. Assemble Water Tank Assy 10
Cautions:
d. before fastening screw, relocate the screw with first thread. Once done fasten the screw.
e. Do not drop, hit or knock the ASO/ PCBA. (ESD wrist strap & proper pack with ESD bag)
f. Ensure there is click sound after Connector to Terminal engagement for wire connection.
