Published by Philips Consumer Lifestyle 19 | P a g e For internal use only
Document No. : CSW-07-081-18111
10. Connect Pump Assy’s Braided Hose to Boiler’s Water Inlet Collar, lock the Inox Clamp with Knipex Crimping
Tool.
11. Assemble Spacer Top 17, assemble Screw L, fasten Screw L
12. Assemble Power PCBA 28 to Button Assy 29, assemble Screw J, fasten Screw J
13. Assemble Screw R, fasten Screw R
14. Assemble Power PCBA 28 & Button Assy 29, connect & dress wiring as shown.
15. Assemble Inlet Coupling Assy 25, Inlet Coupling Seal 24, Connect Corrugated Tube
16. Assemble Screw M, fasten Screw M
17. Assemble Stand Top 23, Connect Return Tube to Front Lock Bracket Assy 11
18. Assemble Tank Catch 16 & Tank Catch Spring
19. Assemble Front Lock Bracket Assy 11, assemble Screw Q, fasten Screw Q
20. Assemble Front Lock Slider Assy 12 and Front Lock Slider Spring
To Next Page
