PHILIPS MEDICAL SYSTEMS
B-10
(OPTIONAL) M3855A CHARGER
(OPTIONAL) M3873A/M3874A FR2+ ECG ASSESSMENT MODULE
category nominal specifications
application For use with M3864A Training & Administration Pack only.
power requirements With appropriate power cord, any AC mains power input or inverter-type
power sources.
storage/transport
temperature
32° to 113° F (0° to 45° C).
conformance testing International: EN60335-1:1994 Class I
North America: UL 1310 Class 2
category nominal specifications
application For use with the FR2+ M3860A with ECG display enabled and running
version 1.5 software or higher (denoted by FR2+ on the front panel or rear
label).
length and weight 100 inches (182 cm); 1 lb. (2.2 kg).
operating temperature 32° to 122° F (0° to 50° C).
storage/transport
temperature
32° to 109° F (0° to 43° C).
patient lead wire designation M3873A (AAMI): M3874A (IEC):
positive lead — red positive lead — green
negative lead — white negative lead — red
reference lead — black reference lead — yellow
typical (lead II) connection Lead II vectors:
positive — left leg
negative — right arm
reference — left arm
Other limb vectors can be obtained by different electrode positions.
battery type 3 V, 1 Ah, poly-carbonmonofluoride lithium (LiCFx). Non-replaceable
disposable primary cell.
service life Typically, 5 years.
performance with FR2+
defibrillator
Meets environmental specifications cited for FR2+ Defibrillator on page B-1
through B-2.
