Philips HTS3440/37 - Technical Specifications and Connection Facilities; General Specifications; Tuner Specifications; Amplifier Specifications

EN 3
3139 785 31880
Technical Specifications and Connection Facilities
1.
1. Specifications
1.1 General:
Mains voltage : 120V/230V
Mains frequency : 50/60Hz
Power consumption : 70W
< 1W Eco standby
power
< 70W at 1/8 P
rated
(For main unit)
Dimension main unit : 435 x 55 x 324mm
1.2 Tuner
FM
Tuning range : 87.5-108MHz
Grid : 100kHz
IF frequency : 10.7MHz ± 25kHz
Aerial input : 75Ω coaxial
Sensitivity at 26dB S/N : < 7µV
Selectivity at 600kHz bandwidth : > 25dB
IF rejection : > 60dB
Image rejection : > 25dB
Distortion at RF=1mV, dev. 75kHz : < 3%
-3dB Limiting point : 8µV
Crosstalk at RF=1mV, dev. 67.5kHz : > 28dB
Crosstalk at RF=1mV, dev. 40kHz : > 18dB
MW
Tuning range : 531-1602kHz
530-1700kHz
Grid : 9kHz
10kHz
IF frequency : 450kHz ± 1kHz
Aerial input : Frame aerial
Sensitivity at 26dB S/N : < 4.0mV/M
Selectivity at 18kHz bandwidth : > 20dB
IF rejection : > 45dB
Image rejection : > 28dB
Distortion at RF=50mV, m=80% : < 5%
1.3 AMPLIFIER:
Output power
Front : 125W RMS / channel
Rear : 125W RMS / channel
Center : 250W RMS
Subwoofer : 250W RMS
Frequency response ±0.5dB : 20Hz-20kHz
Hum (Volume Minimum) : 200nW
Residual noise (Volume Minimum) : 40nW
Input sensitivity
Aux In : 1V ± 3dB at 22kΩ
Scart In : 0.5V ± 3dB at 22kΩ
Output sensitivity
Line Out (Left/Right) : 1V ± 2dB at 10kΩ
Scart Out (Left/Right) : 1V ± 2dB at 10kΩ
1.4 COMPACT DISC/VCD/DVD:
Video Decoding : MPEG-1/MPEG-2/
DivX 3/4/5/6, Ultra
Video DAC : 12 Bits
Signal System : PAL / NTSC
Video Format : 4:3 / 16:9
CVBS Out
1)
CVBS level : 1.0 ± 0.1V
p-p
Luminance S/N : >= 55dB
S-Video Out
1)
Y level : 1.0 ± 0.1V
p-p
Y S/N : >= 55dB
C level (burst) : 286mV
pp
+1/-4 dB
(NTSC)
RGB/YUV Out
1)
Amplitude : 0.7 ± 0.1V
p-p
S/N : >= 60dB
1)
Output terminals to be terminated with 75Ω
