Installation & User’s Manual SL STRIP 400 RGBW LED Luminaires
30 DMX CONTROL
Sh wline
Table 10: SL STRIP 400 RGBW LED Luminaire RDM Manufacturer Status IDs
Manufacturer Specific messages are in the range of 0x8000 - 0xFFDF. Each Manufacturer-specific Status ID shall have a
unique meaning, which shall be consistent across all products having a given Manufacturer ID. See Table B-2, ANSI E1.20-
2010.
Status ID Message Value Data Value 1 Data Value 2 Status ID Description
8100H 00H 00H ALL OK
Table 11: SL STRIP 400 RGBW LED Luminaire RDM Manufacturer Specific PIDs
Get
Allowed
Set
Allowed
RDM
Parameter IDs
Type Length Unit Prefix Min Max Default Description
Category - Manufacturer Defined PIDs - Range is 0x8000-0xffdf (See ANSI E1.20-2010 Standard, Table A-3)
■■
8A00H U8 1 None None 0 100 100 DIMMER
■■
8A04H U8 1 None None 0 100 100 Dimmer RED
■■
8A05H U8 1 None None 0 100 100 Dimmer GREEN
■■
8A06H U8 1 None None 0 100 100 Dimmer BLUE
■■
8A07H U8 1 None None 0 100 100 Dimmer WHITE
■■
8AB2H U8 1 None None 1 18 1 Chase
■■
8AB0H U8 1 None None 0 43 0 Color Filter
■■
8AB1H U8 1 None None 0 31 0 Preset
■■
8A92H U8 1 None None 0 255 0 Strobe
■■
8A94H U8 1 None None 0 255 0 Duration
■■
8AC0H U8 1 None None 0 255 255 Intensity Timing
■■
8AC2H U8 1 None None 0 255 255 Color Timing
■■
8A40H U8 1 None None 0 1 0 Link Mode
■■
8A42H U8 1 None None 0 1 0 Incandescent Effect
■■
8AA1H U8 1 None None 0 3 0 Dimming Curve
■■
8A0CH U8 1 None None 0 3 0 DMX Fail Mode
■■
8AA0H U8 1 None None 0 4 0 Backlight Off Time
■■
8AA2H U8 1 None None 0 94 0 Power Up Setup
■■
8A44H U8 1 None None 0 1 0
Calibration ON/OFF
Setup
■■
8A41H U8 1 None None 0 1 0 Lock Fixture
