Philips IP20 - Technical Specifications; SL STRIP 400 RGBW LED Luminaire Operational Specifications; SL STRIP 400 RGBW LED Luminaire Dimensions

SL STRIP 400 RGBW Luminaire Operational Specifications
32
SL STRIP 400 RGBW LED Luminaires Installation & User’s Manual
Sh wline
TECHNICAL SPECIFICATIONS
1. SL STRIP 400 RGBW LED Luminaire Operational Specifications
Source: RGBW LED Array (x36 - 9 Red / 9 Green / 9 Blue / 9 White - all 600 mA)
Beam Angle: 10 Degrees
Light Output: > 2,300 lumens
Color Temperature: 2700 - 6500K (user adjustable)
Input Voltage (AC): 100V to 240V (+/- 10%, auto-ranging)
Current (AC): 0.95 Amps (100V) / 0.40 Amps (240V)
Frequency: 50/60Hz
Control Protocols: DMX512 (1990) / DMX512A (RDM) / On-Board Menu
Ambient Temperature: -20 to 40 Degrees C (-4 to 104 Degrees F)
Humidity: 5%-95% Non condensing
Cooling: Natural Convection
Weight: 15.0 lbs (6.8 kg) - Luminaire only (no accessories)
Housing: Die Cast Aluminium with Powder Coating
Compliance: CE Marked (International models)
IP Rating: IP20
Note: Common model specifications shown. For specific model specifications, features, and accessories, refer to the
product specification sheet for more details.
2. SL STRIP 400 RGBW LED Luminaire Dimensions
132.5 mm /
5.2 in.
92 mm /
3.6 in.
1000 mm / 39.4 in.
954 mm / 37.6 in.
207.4 mm / 8.17 in.
87.7 mm /
Side View
3.5 in.
Bottom View
End View
70 mm /
2.76 in.
207.4 mm / 8.17 in.439 mm / 17.28 in.
