Philips L9.2A - Spare Parts List

Spare parts list
GB 64 L9.2A10.
10. Spare parts list
Mono Carrier [A]
Various
0127 3122 358 72141 FUSE HOLDER CLICK
0130 3139 123 21331 INSULATING PLATE
0139 4822 492 70788 IC fixation
0189 3139 124 24322 PCB RELIEF BRACKET
0211
h
4822 265 20723 Conn. 2p
0218 4822 265 10481 CINCH CONNECTOR 2P
0223 4822 265 10495 Cinch block
0224 4822 267 10676 Conn. 1p
0228 4822 267 10676 Conn. 1p
0229 4822 267 31673 Headphone plug
0230 4822 267 31673 Headphone plug
0231
h
4822 276 14024 Mains switch
0232
h
4822 267 31014 HEADPHONE SOCKET
0234 4822 267 10928 Conn. 5p
0267 4822 267 31673 Headphone plug
1000
h
4822 210 10841 Tuner UV1316/A
1001 4822 242 10314 filter 5,5MHz
1002 4822 242 10316 filter 6,5MHz
1003 4822 242 10357 SAW filter OFWK2960M
1200 4822 242 10315 cer. filter 5,5/5,7/6,5MHz
1200 4822 242 81712 filter 5,5/5,74MHz
1201 4822 242 81301 filter 6,5MHz
1201 4822 242 81572 filter 6,0MHz
1203 4822 242 81978 filter 4,5MHz
1205 4822 242 10695 crystal 4.433619 MHz
1208 4822 242 10776 crystal 3.579545 MHz
1500
h
4822 070 34002 fuse (4A)
1571
h
4822 071 51002 fuse (1A)
1572
h
4822 252 11194 fuse (0,800A)
1600 4822 242 10694 crystal 12.000MHz
1680 4822 276 13775 SWITCH
1681 4822 276 13775 SWITCH
1682 4822 276 13775 SWITCH
1683 4822 276 13775 SWITCH
g
2001 4822 126 13751 47nF 10% 63V
2002 4822 124 40207 100
µ
F 20% 25V
2003 4822 124 40207 100
µ
F 20% 25V
2004 5322 122 32654 22nF 10% 63V
2005 5322 122 32531 100pF 5% 50V
2006 4822 126 13695 82pF 1% 63V
2008 4822 124 40248 10
µ
F 20% 63V
2009 4822 122 33926 12pF 50V
2010 5322 122 33861 120pF 10% 50V
2011 4822 122 33177 10nF 20% 50V
2012 4822 122 33177 10nF 20% 50V
2013 4822 122 33177 10nF 20% 50V
2110 5322 122 31863 330pF 5% 63V
2111 5322 122 31863 330pF 5% 63V
2112 5322 122 31863 330pF 5% 63V
2113 5322 122 31863 330pF 5% 63V
2114 5322 122 31863 330pF 5% 63V
2115 5322 122 31863 330pF 5% 63V
2135 4822 126 14043 1
µ
F 20% 16V
2136 4822 126 14043 1
µ
F 20% 16V
2137 4822 126 13482 470nF 20% 16V
2172 5322 122 31863 330pF 5% 63V
2173 5322 122 31863 330pF 5% 63V
2174 4822 124 40248 10
µ
F 20% 63V
2176 5322 122 31863 330pF 5% 63V
2177 4822 124 40248 10
µ
F 20% 63V
2201 4822 124 21913 1
µ
F 20% 63V
2202 5322 126 10465 3.9nF 10% 50V
2203 4822 124 40248 10
µ
F 20% 63V
2205 4822 126 13838 100nF 50V 20%
2206 4822 122 33127 2.2nF 10% 63V
2207 4822 124 40207 100
µ
F 20% 25V
2210 4822 126 13482 470nF 20% 16V
2211 4822 126 13482 470nF 20% 16V
2212 5322 126 10511 1nF 5% 50V
2213 4822 126 13482 470nF 20% 16V
2214 5322 122 32654 22nF 10% 63V
2215 4822 124 22652 2.2
µ
F 20% 50V
2216 4822 126 14076 220nF 20% 25V
2217 4822 126 13689 18pF 1% 63V
2218 5322 122 31866 6.8nF 10% 63V
2220 4822 126 13838 100nF 20% 50V
2221 5322 126 10511 1nF 5% 50V
2222 4822 126 13838 100nF 20% 50V
2223 4822 126 13751 47nF 10% 63V
2224 4822 126 13751 47nF 10% 63V
2225 4822 126 13751 47nF 10% 63V
2226 4822 124 40248 10
µ
F 20% 63V
2227 4822 051 20008 jumper (0805)
2227 4822 126 13482 470nF 20% 16V
2228 4822 126 13692 47pF 1% 63V
2229 4822 126 13692 47pF 1% 63V
2230 4822 126 13692 47pF 1% 63V
2231 4822 122 33177 10nF 20% 50V
2232 4822 122 33127 2.2nF 10% 63V
2233 4822 124 21913 1
µ
F 20% 63V
2234 5322 126 10223 4.7nF 10% 63V
2236 4822 126 14076 220nF 20% 25V
2237 5322 122 32531 100pF 5% 50V
2238 4822 126 13486 15pF 2% 63V
2239 5322 121 42386 100nF 5% 63V
2240 5322 126 10511 1nF 5% 50V
2241 5322 126 10511 1nF 5% 50V
2242 4822 124 21913 1
µ
F 20% 63V
2243 4822 126 14076 220nF 20% 25V
2244 4822 124 40248 10
µ
F 20% 63V
2248 4822 126 13486 15pF 2% 63V
2250 5322 122 31863 330pF 5% 63V
2253 5322 122 32654 22nF 10% 63V
2255 5322 122 32531 100pF 5% 50V
2313 4822 122 33216 270pF 5% 50V
2323 4822 122 33172 390pF 5% 50V
2331 5322 122 31863 330pF 5% 63V
2341
h
4822 126 14588 2.2nF 10% 1KV
2342 4822 121 43526 47nF 5% 250V
2343 4822 121 43526 47nF 5% 250V
2400 4822 121 43526 47nF 5% 250V
2401 4822 121 43526 47nF 5% 250V
2402 5322 122 31863 330pF 5% 63V
2403 4822 122 31169 1.5nF 10% 500V
2405
h
4822 126 14237 470pF 10% R 2KV
2406
h
4822 126 13866 4.7nF 10% 1KV
2407
h
4822 121 70434 11nF 5% 1.6KV
2407
h
4822 121 70617 10nF 5% 1.6KV
2407
h
4822 121 70637 8.2nF 5% 1600V
2408 4822 122 30103 22nF 20% 63V
2409 4822 124 11575 47
µ
F 20% 160V
2410 4822 124 11767 470
µ
F 20% 25V
2411 4822 124 40255 100
µ
F 20% 63V
2412 4822 121 51385 33nF 20% 100V
2413 4822 124 11845 22
µ
F 20% 250V
2414 4822 124 81145 1000
µ
F 20% 16V
2415 4822 124 81145 1000
µ
F 20% 16V
2416
h
4822 126 11503 820pF 10% 2KV
2416
h
4822 126 12263 220pF 10% 2KV
2416
h
4822 126 13864 330pF 10% 2KV
2417 4822 124 11767 470
µ
F 20% 25V
2418 4822 126 13482 470nF 20% 16V
2420 4822 121 10781 470nF 5% 250V
2420 4822 126 14097 680nF 5% 250V
2431 4822 124 12438 2.2
µ
F 20% 100V
2432 4822 124 81188 100
µ
F 20% 25V
2460 5322 122 32268 470pF 10% 50V
2461 5322 126 10184 820P 5% 50V
2462 5322 122 32268 470pF 10% 50V
2463 5322 121 42386 100nF 5% 63V
2464 4822 124 40255 100
µ
F 20% 63V
2465 5322 121 42386 100nF 5% 63V
2466 4822 121 42408 220nF 5% 63V
2467 5322 121 42386 100nF 5% 63V
2470 5322 126 10223 4.7nF 10% 63V
2500
h
4822 126 13589 470nF 275V
2502
h
4822 126 14153 2.2nF 10% 1KV
2504
h
4822 126 14153 2.2nF 10% 1KV
2505
h
4822 126 14153 2.2nF 10% 1KV
2508 4822 124 12415 220
µ
F 20% 400V
2509
h
4822 126 13517 820pF 10% 1000V
2510
h
4822 126 13517 820pF 10% 1000V
2517 5322 122 32331 1nF 10% 100V
2518
h
4822 126 13337 220pF 10% 1KV
2518
h
4822 126 14149 330pF 10% 1KV
2520 4822 126 13695 82pF 1% 63V
2521 4822 122 33891 3.3nF 10% 63V
2521 5322 126 10223 4.7nF 10% 63V
2522 4822 122 33891 3.3nF 10% 63V
2522 5322 126 10223 4.7nF 10% 63V
2524 5322 122 32268 470pF 10% 50V
2529 4822 126 13838 100nF 20% 50V
2530 4822 124 22776 1
µ
F 50V
2531 4822 126 14587 560pF 2% 50V
2533 5322 122 31863 330pF 5% 63V
2534 5322 126 10511 1nF 5% 50V
2537 5322 121 42386 100nF 5% 63V
2540 4822 124 81188 100
µ
F 20% 25V
2541 4822 121 10686 4.7nF 10% 50V
2545
h
4822 126 14049 1.5nF 20% 250V
2550
h
4822 126 14152 680pF 10% 1KV
2551 4822 124 42336 47
µ
F 20% 160V
2560 5322 122 31647 1nF 10% 63V
2561 4822 124 81145 1000
µ
F 20% 16V
2570 4822 122 33127 2.2nF 10% 63V
2571 4822 124 12417 2200
µ
F 20% 25V
2572 4822 122 33177 10nF 20% 50V
2600 4822 124 81151 22
µ
F 50V
2601 4822 124 81151 22
µ
F 50V
2604 4822 126 13838 100nF 20% 50V
2605 4822 126 13838 100nF 20% 50V
2606 4822 126 13838 100nF 20% 50V
2607 5322 126 10511 1nF 5% 50V
2608 4822 121 43897 1nF 5% 400V
2609 4822 126 13838 100nF 20% 50V
2610 4822 121 42687 3.3nF 10% 63V
2611 4822 126 13838 100nF 20% 50V
2612 5322 122 32654 22nF 10% 63V
2613 4822 126 13695 82pF 1% 63V
2614 4822 126 13695 82pF 1% 63V
2615 5322 122 32531 100pF 5% 50V
2616 5322 122 32658 22pF 5% 50V
2617 5322 122 32658 22pF 5% 50V
2618 4822 122 33177 10nF 20% 50V
2619 4822 126 14076 220nF 20% 25V
2620 5322 122 32531 100pF 5% 50V
2621 5322 122 32531 100pF 5% 50V
2622 5322 122 32531 100pF 5% 50V
2623 5322 122 32531 100pF 5% 50V
2624 4822 126 13838 100nF 20% 50V
2625 5322 122 32531 100pF 5% 50V
2651 4822 124 40207 100
µ
F 20% 25V
2675 4822 126 13482 470nF 20% 16V
2680 4822 124 40248 10
µ
F 20% 63V
2697 5322 126 10511 1nF 5% 50V
2950 4822 124 81151 22
µ
F 50V
2951 4822 124 40248 10
µ
F 20% 63V
2952 4822 122 33127 2.2nF 10% 63V
2953 4822 126 14076 220nF 20% 25V
2954 4822 126 14076 220nF 20% 25V
2955 4822 124 11767 470
µ
F 20% 25V
2971 4822 121 51252 470nF 5% 63V
2972 4822 126 12105 33nF 5% 50V
2973 5322 121 42386 100nF 5% 63V
2974 4822 121 51379 82nF 5% 63V
2975 4822 122 33177 10nF 20% 50V
f
3000 4822 051 20101 100
Ω
5% 0.1W
3001 4822 051 20101 100
Ω
5% 0.1W
3002 4822 116 52244 15k 5% 0.5W
3003 4822 116 52238 12k 5% 0.5W
3004 4822 116 52243 1k5 5% 0.5W
3013 4822 051 20008 jumper (0805)
3014 4822 051 20392 3k9 5% 0.1W
3015 4822 116 83933 15k 1% 0.1W
3016 4822 117 10361 680
Ω
1% 0.1W
3021 4822 117 10361 680
Ω
1% 0.1W
3026 4822 051 20562 5k6 5% 0.1W
3027 4822 051 20223 22k 5% 0.1W
3110 4822 117 11927 75
Ω
1% 0.1W
3112 4822 051 20101 100
Ω
5% 0.1W
3113 4822 051 10102 1k 2% 0.25W
3114 4822 050 11002 1k 1% 0.4W
3115 4822 117 10834 47k 1% 0.1W
3117 4822 051 20008 jumper (0805)
3120 4822 117 11927 75
Ω
1% 0.1W
3121 4822 117 10353 150
Ω
1% 0.1W
3122 4822 117 13579 220k 1% 0.1W
3124 4822 117 10353 150
Ω
1% 0.1W
3125 4822 117 13579 220k 1% 0.1W
3127 4822 051 20008 jumper (0805)
3128 4822 117 10834 47k 1% 0.1W
3140 4822 116 83874 220k 5% 0.5W
3141 4822 050 11002 1k 1% 0.4W
3145 4822 116 52228 680
Ω
5% 0.5W
3146 4822 051 20334 330k 5% 0.1W
3147 4822 051 20391 390
Ω
5% 0.1W
