Philips L9.2A - Page 34

Spare parts list
GB 66 L9.2A10.
6401 4822 130 30621 1N4148
6402 4822 130 42488 BYD33D
6404 4822 130 32896 BYD33M
6405 4822 130 42488 BYD33D
6406 4822 130 30621 1N4148
6409 4822 130 42488 BYD33D
6410 4822 130 42488 BYD33D
6412 4822 130 42488 BYD33D
6413 4822 130 34197 BZX79-B12
6414 4822 130 83757 BAS216
6415 4822 130 83757 BAS216
6418 4822 130 30621 1N4148
6419 4822 130 30621 1N4148
6431 4822 130 30842 BAV21
6432 4822 130 30621 1N4148
6435 4822 130 83757 BAS216
6460 4822 130 42488 BYD33D
6461 4822 130 34142 BZX79-B33
6502 4822 130 31083 BYW55
6503 4822 130 31083 BYW55
6504 4822 130 31083 BYW55
6505 4822 130 31083 BYW55
6507 4822 130 31393 BYT52J
6507 4822 130 42606 BYD33J
6508 4822 130 31393 BYT52J
6508 4822 130 42606 BYD33J
6537 4822 130 30842 BAV21
6540 4822 130 30842 BAV21
6550 4822 130 10218 BY229X-800
6560 4822 130 10871 SBYV27-200
6570 4822 130 10256 EGP20DL-5300
6600 4822 130 11366 BZX284-C3V9
6601 4822 130 10852 BZX284-C6V8
6612 4822 130 34278 BZX79-B6V8
6669 4822 130 34233 BZX79-B5V1
6953 4822 130 10756 BZX284-C2V7
ce
7010 4822 209 90008 L78M05CP
7116 4822 130 60511 BC847B
7118 4822 130 60511 BC847B
7206 4822 130 60373 BC856B
7250 4822 209 16775 TDA8842/N2/S1
7252 4822 130 60373 BC856B
7253 4822 130 60373 BC856B
7256 4822 130 60511 BC847B
7265 4822 130 40981 BC337-25
7266 4822 130 60511 BC847B
7311 4822 130 41782 BF422
7312 4822 130 41782 BF422
7313 4822 130 41646 BF423
7321 4822 130 41782 BF422
7322 4822 130 41782 BF422
7323 4822 130 41646 BF423
7331 4822 130 41782 BF422
7332 4822 130 41782 BF422
7333 4822 130 41646 BF423
7400 4822 130 41782 BF422
7401 4822 130 60373 BC856B
7402 4822 130 11575 BUT11APX
7431 4822 130 60373 BC856B
7460 4822 209 13176 TDA9302H
7469 4822 130 60511 BC847B
7518 4822 130 10806 STP6NA60FI
7520 4822 209 15684 MC44603AP
7600 4822 209 17537 SAA5563/M2A/0018
7600 4822 209 17538 SAA5542PS/M2A/0017
7600 9352 636 28112 IC SAA5563PS/M2/0037
7601 4822 209 15546 ST24W08B6
7602 4822 130 41109 BD135-16
7605 4822 130 60511 BC847B
7607 5322 209 60154 NE555D
7608 4822 209 73852 PMBT2369
7609 4822 130 60511 BC847B
7610 4822 130 60511 BC847B
7611 4822 130 60511 BC847B
7612 4822 130 41109 BD135-16
7620 4822 130 40959 BC547B
7621 4822 130 60511 BC847B
7680 4822 218 12055 TSOP2836UH1
7951 4822 130 60511 BC847B
7952 4822 130 60511 BC847B
7953 4822 209 90462 TDA7056B/N1
7955 4822 130 60511 BC847B
7956 4822 130 60373 BC856B
CRT[B]
Various
0254
h
4822 267 20466 Conn. 9p
0254
h
4822 255 70293 CRT socket 14" ANS
1015 3139 178 03401 CRT PANEL 14 "
1015 3139 178 03391 CRT PANEL 20"
1015 3139 177 19321 CRT PANEL 21"
g
2313 4822 122 33216 270pF 5% 50V
2323 4822 122 33172 390pF 5% 50V
2331 5322 122 31863 330pF 5% 63V
2341
h
4822 126 14588 2.2nF 10% 1KV
2342 4822 121 43526 47nF 5% 250V
2343 4822 121 43526 47nF 5% 250V
f
3311 4822 051 10102 1k 2% 0.25W
3312 4822 117 13577 330
Ω
1% 1.25W
3313 4822 051 20109 10
Ω
5% 0.1W
3314 4822 053 12183 18k 5% 3W
3316
h
4822 052 10221 220
Ω
5% 0.33W
3317 4822 052 11152 1k5 5% 0.5W
3321 4822 051 10102 1k 2% 0.25W
3322 4822 117 13577 330
Ω
1% 1.25W
3323 4822 051 20109 10
Ω
5% 0.1W
3324 4822 053 12183 18k 5% 3W
3326
h
4822 052 10221 220
Ω
5% 0.33W
3327 4822 052 11152 1k5 5% 0.5W
3331 4822 051 10102 1k 2% 0.25W
3332 4822 117 13577 330
Ω
1% 1.25W
3333 4822 051 20109 10
Ω
5% 0.1W
3334 4822 053 12183 18k 5% 3W
3336
h
4822 052 10221 220
Ω
5% 0.33W
3337 4822 052 11152 1k5 5% 0.5W
3341 4822 052 11152 1k5 5% 0.5W
3347
h
4822 052 10102 1k 5% 0.33W
3348 4822 052 11152 1k5 5% 0.5W
3349
h
4822 052 10108 1
Ω
5% 0.33W
3349
h
4822 052 10128 1
Ω
2 5% 0.33W
3349
h
4822 052 10158 1
Ω
5 5% 0.33W
3350
h
4822 052 10108 1
Ω
5% 0.33W
3350
h
4822 052 10128 1
Ω
2 5% 0.33W
3350
h
4822 052 10158 1
Ω
5 5% 0.33W
b
5341 4822 157 51157 3.3
µ
H
5341 4822 157 71401 27
µ
H
5341 4822 158 10604 6.8
µ
H
5342 4822 526 10704 100mH z
d
6311 4822 130 30842 BAV21
6321 4822 130 30842 BAV21
6331 4822 130 30842 BAV21
6341 4822 130 30842 BAV21
6342 4822 130 30621 1N4148
6343 4822 130 11666 BZX284-C8V2
ce
7311 4822 130 41782 BF422
7312 4822 130 41782 BF422
7313 4822 130 41646 BF423
7321 4822 130 41782 BF422
7322 4822 130 41782 BF422
7323 4822 130 41646 BF423
7331 4822 130 41782 BF422
7332 4822 130 41782 BF422
7333 4822 130 41646 BF423
Sound[D]
Various
0239 4822 267 11052 Conn. 17P
0240 4822 267 11052 Conn. 17P
0248 4822 267 31673 HEADPHONE PLUG
1801 4822 242 10769 crystal 18.432MHz
g
2801 5322 122 32658 22pF 5% 50V
2804 4822 122 33926 12pF 50V
2805 5322 126 10225 1P5 5%
2806 5322 126 10225 1P5 5%
2807 4822 126 14076 220nF 20% 25V
2808 4822 126 14076 220nF 20% 25V
2809 4822 126 14076 220nF 20% 25V
2810 4822 126 14076 220nF 20% 25V
2814 4822 126 13838 100nF 20% 50V
2815 4822 126 13692 47pF 1% 63V
2820 4822 124 40248 10
µ
F 20% 63V
2821 4822 126 13838 100nF 20% 50V
2822 4822 124 40248 10
µ
F 20% 63V
2823 4822 126 13838 100nF 20% 50V
2824 4822 124 40248 10
µ
F 20% 63V
2825 4822 126 13838 100nF 20% 50V
2827 4822 124 40769 4.7
µ
F 20% 100V
2828 5322 126 10511 1nF 5% 50V
2829 4822 124 40769 4.7
µ
F 20% 100V
2830 5322 126 10511 1nF 5% 50V
2831 4822 124 40248 10
µ
F 20% 63V
2835 4822 126 13838 100nF 20% 50V
2836 4822 126 13838 100nF 20% 50V
2837 4822 126 13692 47pF 1% 63V
2838 4822 126 13692 47pF 1% 63V
2841 4822 124 40207 100
µ
F 20% 25V
2842 4822 124 40207 100
µ
F 20% 25V
2950 4822 124 81151 22
µ
F 50V
2951 4822 124 40248 10
µ
F 20% 63V
2952 4822 122 33891 3.3nF 10% 63V
2953 4822 126 14076 220nF 20% 25V
2954 5322 121 42386 100nF 5% 63V
2955 4822 124 11767 470
µ
F 20% 25V
2958 4822 126 13692 47pF 1% 63V
2959 4822 126 13692 47pF 1% 63V
2960 4822 126 13692 47pF 1% 63V
2961 4822 126 13692 47pF 1% 63V
2962 4822 122 33891 3.3nF 10% 63V
2963 4822 126 14076 220nF 20% 25V
2965 4822 126 14076 220nF 20% 25V
f
3807 4822 116 52175 100
Ω
5% 0.5W
3808 4822 116 52175 100
Ω
5% 0.5W
3809 4822 117 10834 47k 1% 0.1W
3810 4822 051 20101 100
Ω
5% 0.1W
3811 4822 051 20101 100
Ω
5% 0.1W
3812
h
4822 052 10688 6
Ω
8 5% 0.33W
3950 4822 051 20273 27k 5% 0.1W
3953 4822 051 20332 3k3 5% 0.1W
4xxx 4822 051 10008 0
Ω
5% 0.25W
4xxx 4822 051 20008 0
Ω
5% 0.25W
b
5801 4822 157 50965
5811 4822 157 51462 10
µ
H 10%
5812 4822 157 51462 10
µ
H 10%
5813 4822 157 51462 10
µ
H 10%
5814 4822 157 53139 4.7
µ
H
d
6801 4822 130 30621 1N4148
6802 4822 130 34382 BZX79-B8V2
6953 5322 130 31504 BZX79-B3V3
ce
7803 4822 209 17461 MSP3415D-PP-A2
7953 4822 209 13646 TDA7057AQ/N2
7956 4822 130 60373 BC856B
Side AV [E]
Various
0021 3139 124 26931 SIDE AV Bracket
0250 4822 265 11606 Conn. 3P
