8.6 Sam Menu
8.6.1 SAM Menu
Figure 8-2 SAM Menu
8.6.2 White Tone
In the White Tone sub menu the colour values for the colour
temperature values can be changed.
The colour temperature mode (Normal, Delta Cool, Delta
Warm) or the colour (R, G, B) can be selected with the Right/
Left cursor keys. The mode or value can be changed with the
Up/Down cursor keys.
First the values for the Normal colour temperature should be
selected. Range: 0-255, 128 represent the middle of the value
(no offset difference). Then the offset values for the Delta Cool
and Delta Warm mode can be selected. Note that the
alignment values are non-linear. The range is: -50 to +50, 0
represents the middle value, (no offset difference).
Input signal strength: >=10 mV_rms (80 dBµV) terminal
voltage.
Input injection point: Aerial input.
Alignment Method
Initial Set-up
• 12 minutes soaking time before carrying out Colour Temp
alignment.
• Incredible Picture/Contrast+ and Active Control & Light Sensor must be switched Off for proper tracking.
SAM SAM
. OP1 0 . Delta Cool Red -3
. OP2 57 . Delta Cool Green -1
. OP3 140 . Delta Cool Blue 5
. OP4 32
. OP5 120
. OP6 128
. OP7 0
SAM SAM
. IFPLL 32 . Normal Red 32
. AGC 30 . Normal Green 35
. AGCL' 255 . Normal Blue 41
SAM SAM
. Cool . Delta Warm Red 2
. Normal . Delta Warm Green -3
. Warm . Delta Warm Blue -13
SAM
. QSS Off
. FMI On
. NICAM Alignment 63
. DBE Off
SAM
.ADR 0x0000 0
.VAL 0x0000 0
.Store Store ?
SAM
.ADR 0x0000 0
.VAL 0x0000 0
.Store Store ?
F_15310_004.eps
200605
00022 LC4CEP1 1.05/S4CEX1 1.06 SAM
ERR 0 0 0 0 0
OP 000 057 140 032 120 128 000
. Clear Clear ?
. Options
. Tuner
. White Tone
. Audio
. NVM Editor
. SC NVM Editor
. ComPair Mode On
1 00022 LC4CEP1 1.05/S4CEX1 1.06 CSM
2 CODES 0 0 0 0 0
3 OP 000 057 140 032 120 128 000
4 20PF8846/12
5
6 NOT TUNED
7 PAL
8 STEREO
9 CO 50 CL 50 BR 50
0 AVL Off
00022 LC4CEP1 1.05/S4CEX1 1.06 SDM
ERR 0 0 0 0 0
OP 000 057 140 032 120 128 000
To Next Page
