1-1 FL13.16SP
SPECIFICATIONS
< TUNER / NTSC >
ANT. Input ---------------------- 75 Ω Unbal., F type
< TUNER / ATSC >
< LCD PANEL >
< VIDEO >
< AUDIO >
All items are measured across 8 Ω load at speaker output terminal with L.P.F.
Description Condition Unit Nominal Limit
1. AFT Pull-In Range --- MHz ±2.3 ±2.1
2. Synchronizing Sens.
TV.ch.4
CA.ch.31
CA.ch.87
dBµV
dBµV
dBµV
18
18
18
20
20
23
Description Condition Unit Nominal Limit
1. Received Freq. Range (-28dBm) --- kHz --- ±100
2. ATSC Dynamic Range (min / max)
ch.4
ch.10
ch.41
dBm
dBm
dBm
---
---
---
-76/0
-76/0
-76/+4
Description Condition Unit Nominal Limit
1. Native Pixel Resolution
Horizontal
Vertical
pixels
pixels
1920
1080
---
---
2. Brightness (w / filter) ---
cd/m
2
270 ---
3. Viewing Angle
Horizontal
Vertical
°
°
-88 to 88
-88 to 88
---
---
Description Condition Unit Nominal Limit
1. Over Scan
Horizontal
Vertical
%
%
5
5
5±5
5±5
2. Color Temperature
---
x
y
°K 12000
0.272
0.278
---
±3%
±3%
<Measurement condition>
Input signal: HDMI1 Raster (40/80IRE) 1080i@60
Measurement point: Screen center
Measuring instrument:
Made of KONICA MINOLTA Luminance meter CA-310
Aging time: 60min. (Retail MODE / 100IRE Raster HDMI
1080i@60)
MODE setting of TV: Shipment setting / Retail MODE
Ambient temperature: 25°C ±5°C
3. Resolution (composite video)
Horizontal
Vertical
line
line
400
350
---
---
Description Condition Unit Nominal Limit
1.
Audio MAX Output (ATSC 0dBfs)
Lch/Rch W 10.0/10.0 9.0/9.0
2. Audio Distortion (NTSC) 500mW: Lch/Rch % 0.5/0.5 2.0/2.0
