Philips LF501EM4 - TYPE A PARTS LIST

2013/02/06 13-1 A3AUECA.fm
TYPE A
PARTS LIST [LF501EM4 (Serial No.: DS1)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
LCD PANEL ASSEMBLY
Ref.No. Description Part No.
A3 REAR COVER A3AU0UH 1EM030226
A4-1 BOTTOM COVER L A3AU0UH 1EM030227
A4-2 BOTTOM COVER R A3AU0UH 1EM030228
A7 FUNCTION KNOB A3AU0UH 1EM334497
A13 JACK HOLDER A3AU0UH 1EM334651
A15# RATING LABEL A3AU0UH ----------
A16 LOGO LABEL A3AU0UH ----------
A17 ENERGY GUIDE LABEL A3AU0UH ----------
AC601# AC CORD W/O A GND WIRE UL/CSA/1775/NO/
BLACK
WAC172LTE010
B2 CLOTH(15X40XT0.5) A7140UH 1EM424366
B10 STAND BRACKET A3AU0UH 1EM030229
B12 SENSOR PLATE A3AU0UH 1EM334578
B17 WALL MOUNT BRACKET M6 A21U0UD 1EM332001
B23 WIRE LABEL A3AF0UT ----------
CL3013 FFC WIRE ASSEMBLY 51PIN W/SHIELD
117001-51813
WX1U3AU0-F01
CL3101 FFC WIRE ASSEMBLY 9PIN 9PIN/WHITE/
322.5MM
WX1A3AU0S105
CL3701 FFC WIRE ASSEMBLY 23PIN 23PIN/WHITE/
205MM
WX1A3AU0S103
CL3801 WIRE ASSEMBLY 4PIN 4PIN/395MM&160MM WX1A3AU0C303
CL4001 WIRE ASSEMBLY 2PIN 2PIN/360MM WX1A3AU0C304
L6 SCREW P-TIGHT M3*10 WASHERHEAD+ GCJP3100
L10 SCREW P-TIGHT 3X12 WASHER HEAD+BLK GCHP3120
L23 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L24 S-TIGHT SCREW M3X6 BIND HEAD+BLACK GBHS3060
L44 SCREW SEMS M4X8 PAN HEAD + FPJ34080
SBA1 50W STAND BASE ASSEMBLY (FC) A21U0UD 1EMN29162
SNA1 50W STAND HINGE ASSEMBLY (FC) A21U0UD 1EMN29161
SP3801 SPEAKER MAGNETIC 8Ω/10W S0411F19 DS08110XQ004
SP3802 SPEAKER MAGNETIC 8Ω/10W S0411F19 DS08110XQ004
SSK1 STAND SCREW KIT A3AU0UH(DOUBLE SEMS
SCREW M4X12 + BLAK)
1ESA34506
PAC K IN G
S1 CARTON A3AU0UH 1EM334653
S3 STYROFOAM TOP A3AU0UH 1EM030620
S4 STYROFOAM BOTTOM A3AU0UH 1EM030925
S5 STYROFOAM CENTER A3AU0UH 2EMC00017
S6 SET BAG A21UHUH 1EM334730
S7 SERIAL NO. LABEL A01PBUH ----------
S9 PAD(580X360X35) A3AU0UH 1EM440437
ACCESSORIES
X1 POLYETHYLENE BAG HDPE 180X340XT0.03 1EM435579
X2# OWNERS MANUAL A31T0UH 1EMN30379
X3 REMOTE CONTROL UNIT NH303UD NH303UD
X4 BATTERY DRY R03(SIZE AAA ) XB00M0RKT001
X6 QUICK START GUIDE A31T0UH 1EMN30382
X7 REGISTRATION CARD (EMERSON) A17N1UH 1EMN27763A
X12 CABLE MANAGEMENT TIE(BLACK) A01F2UH 1EM431197
X22 WARNING MESSAGE FLIER A3AU2UH 2EMN00059
Ref. No. Description Part No.
LCD1# LCD PANEL ASSEMBLY U3AU0R0
Consists of the following
A1 FRONT CABINET A3AU0UH 1EM030225
A9 SENSOR LENS A3AU0UH 1EM334557
A21 BLIND LABEL A3AU0UH ----------
L10 SCREW P-TIGHT 3X12 WASHER HEAD+BLK GCHP3120
LCD MODULE ----------
Ref.No. Description Part No.
