Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DIGITAL MAIN CBA UNIT
MSW ASSEMBLY
POWER SUPPLY CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT A3AUEMMA-001
Ref. No. Description Part No.
MSW ASSEMBLY A3AUCMSW-001
Consists of the following
FUNCTION CBA UNIT ----------
IR SENSOR CBA UNIT ----------
Ref. No. Description Part No.
POWER SUPPLY CBA
Consists of the following
A3AUCMPW-001
CAPACITORS
C601# CAP METALLIZED FILM 0.22µF/310V /K/LE-MX CTA2240DC001
C602 CAP METALLIZED FILM 0.1µF/310V /K/LE-MX CTA1040DC001
C604# CAP METALLIZED FILM 0.1µF/310V /K/LE-MX CTA1040DC001
C605 CAP ELE 33µF/400V/M/85 CEN3300V8007
C606 CERAMIC CAP RB 1000pF/2kV CA3D102TE006
C607 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C608 CHIP CERAMIC CAP. CH J 150pF/50V CHD1JJ3CH151
C610 CHIP CERAMIC CAP. B K 220pF/50V CHD1JK30B221
C611 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C612 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C614# CAP METALLIZED FILM 1.0µF/310V /K/LE-MX CTA1050DC001
C615 CAP ELE 47µF/50V/M/85 CEF4700V8006
C616 CAP ELE 220µF/35V/M/85 CEE2210V8006
C619# SAFTY CAP. 1000pF/250V KX CA2E102MR101
C620 CAP ELE 33µF/35V/M/85 CEE3300V8006
C621 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C622 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C624 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C625 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C631 RES CHIP 1608 1/10W J 1.0k Ω RRXA102HH013
C650 CAP CERAMIC HV 2200pF/1kV B K CA3A222TE006
C651 CAP ELE 470µF/25V/M/85 CED4710V8006
C652 CAP ELE 470µF/25V/M/85 CED4710V8006
C654 CAP ELE 470µF/16V/M/85 CEC4710V8006
C655 CAP ELE 470µF/16V/M/85 CEC4710V8006
C656 CAP ELE 1µF/50V/M/85 CEF1R00V8006
C660 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C662 CAP ELE 22µF/50V/M/85 CEF2200V8006
C663 CAP ELE 100µF/10V/M/85 CEB1010V8006
C665 CERAMIC CAP. RB 680pF/2kV CA3D681TE006
C691 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C692 CAP ELE 33µF/35V/M/85 CEE3300V8006
C721 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C722 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C723 CAP ELE 470µF/63V/M/85 CEG4710V8007
C724 CAP ELE 470µF/63V/M/85 CEG4710V8007
C725 CAP CERAMIC HV 2200pF/1kV B K CA3A222TE006
C726 CERAMIC CAP RB 1500pF/2kV CA3D152TE006
C1001 CAP ELE 470µF/63V/M/85 CEG4710V8007
C1004 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1101 CAP ELE 100µF/63V/M/85 CEG1010V8006
C1102 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1103 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1105 CAP ELE 100µF/100V/M/85 CEH1010V8007
C1107 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1108 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1109 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1110 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1112 CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C1113 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1114 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1115 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V CHD1JK30B223
C1116 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1117 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1118 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1119 CHIP CERAMIC CAP. B K 560pF/50V CHD1JK30B561
C1201 CAP ELE 100µF/63V/M/85 CEG1010V8006
C1202 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1203 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1205 CAP ELE 100µF/100V/M/85 CEH1010V8007
C1207 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1208 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1209 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1210 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1212 CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C1213 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1214 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1215 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V CHD1JK30B223
C1216 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1217 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1218 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1219 CHIP CERAMIC CAP. B K 560pF/50V CHD1JK30B561
C1301 CAP ELE 100µF/63V/M/85 CEG1010V8006
C1302 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1303 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1305 CAP ELE 100µF/100V/M/85 CEH1010V8007
C1307 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1308 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1309 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1310 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
Ref. No. Description Part No.
To Next Page
