Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Different parts from the original model
LF501EM4 (Serial No. : DS1)
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT A3AU1MMA-001
MSW ASSEMBLY A3AU0MSW-001
POWER SUPPLY CBA A3AU0MPW-001
C631 Not used
Q657 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
R676 METAL OXIDE FILM RES. 2W J 6.8 Ω RN026R8ZU001
R678 METAL OXIDE FILM RES. 2W J 6.8 Ω RN026R8ZU001
R679 METAL OXIDE FILM RES. 2W J 6.8 Ω RN026R8ZU001
R683 RES CHIP 3216 1/4W J 3.9 Ω RRX43R9HH034
R684 RES CHIP 3216 1/4W J 3.9 Ω RRX43R9HH034
R685 RES CHIP 3216 1/4W J 3.3 Ω RRX43R3HH034
R686 RES CHIP 3216 1/4W J 3.3 Ω RRX43R3HH034
R687 RES CHIP 3216 1/4W J 3.3 Ω RRX43R3HH034
R688 RES CHIP 3216 1/4W J 2.2 Ω RRX42R2HH034
R689 RES CHIP 3216 1/4W J 2.7 Ω RRX42R7HH034
