Philips MC-M570/21 - ELECTRICAL PARTS LIST - FRONT BOARD; Resistors; Coils & Filters; Diodes

6-10
ELECTRICAL PARTS LIST - FRONT BOARD
RESISTORS
4455 4822 051 30008 0R Jumper 0603
4456 4822 051 30008 0R Jumper 0603
4457 4822 051 30008 0R Jumper 0603
4458 4822 051 30008 0R Jumper 0603
4459 4822 051 30008 0R Jumper 0603
4460 4822 051 30008 0R Jumper 0603
4461 4822 051 30008 0R Jumper 0603
4462 4822 051 30008 0R Jumper 0603
COILS & FILTERS
5300 3198 018 52280 Coil 2,2uH 10%
5301 3198 018 52280 Coil 2,2uH 10%
5302 3198 018 52280 Coil 2,2uH 10%
5401 3198 018 54780 Coil 4,7uH 10%
5402 3198 018 54780 Coil 4,7uH 10%
5403 2422 543 01069 RES XTL 32,768kHz
5404 5322 242 73686 RES CER 12MHz
5405 4822 242 11033 RES XTL 4,332MHz /22
5406 3198 018 52280 Coil 2,2uH 10% /22
5407 3198 018 52280 Coil 2,2uH 10%
5408 3198 018 54780 Coil 4,7uH 10%
5409 3198 018 54780 Coil 4,7uH 10%
5410 3198 018 54780 Coil 4,7uH 10%
5411 3198 018 54780 Coil 4,7uH 10%
DIODES
6300 4822 130 30621 1N4148
6301 9322 179 76676 LED VS LTL-816EELC
6302 9322 178 15676 LED VS LTL-8166FTNN
6303 9322 178 15676 LED VS LTL-8166FTNN
6304 9322 178 15676 LED VS LTL-8166FTNN
6305 9322 178 15676 LED VS LTL-8166FTNN
6306 9322 178 15676 LED VS LTL-8166FTNN
6307 9322 178 15676 LED VS LTL-8166FTNN
6401 4822 130 30621 1N4148
6403 4822 130 31878 1N4003G
6404 4822 130 34278 BZX79-B6V8
6405 4822 130 31878 1N4003G
6406 4822 130 31878 1N4003G
6407 4822 130 30621 1N4148
6408 4822 130 30621 1N4148
6409 4822 130 30621 1N4148
6410 4822 130 30621 1N4148
TRANSISTORS & INTEGRATED CIRCUITS
7301 9322 185 97667 IR Receiver TSOP4836ZC1
7400 3139 110 53371 TMP88CU74YF - '570S53371'
7401 9322 145 26668 M24C02-WMN6
7403 9352 686 05118 SAA6581T /22
7404 5322 130 60159 BC847B
7405 5322 130 60159 BC847B
7406 4822 130 60373 BC857B
7407 4822 209 15449 74HC4094D
Note : Only the parts mentioned in this list are normal
service spare parts.
